Airtac 2KWX Fluid Solenoid Valve 2KWX03008B
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX03008B Fluid Solenoid Valve Specifications
- Model: 2KWX03008B
- Type: 3-position, 5-way (closed center type)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.1–0.7 MPa (14.5–101.5 PSI)
- Fluid compatibility: Air (non-lubricated or lubricated)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -5℃ to 80℃ (with no ice formation)
- Body material: Die-cast aluminum alloy with epoxy coating
- Protection rating: IP67 (dust-tight and protected against immersion)
- Weight: 420g ±5% (including connector)
- Dimensions: 56mm(W) × 48mm(H) × 118mm(L)
- Port thread depth: 12mm (minimum engagement 9 threads)
- Max flow rate: 750 L/min (ANR) at 0.5MPa
High-flow proportional control valve with closed-center configuration, featuring dual-coil latching design for energy efficiency. The dual-chamber diaphragm structure ensures stable switching even under pressure fluctuations. Optimized flow path geometry reduces pressure drop by 18% compared to previous generations. Includes surge protection circuitry and LED status indicator.
- Plastic injection molding machine sequence control
- Automated assembly line clamping systems
- Industrial cleaning equipment pressure regulation
- CNC machine tool coolant control
- Beverage filling station pneumatic circuits
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m).
Maintain minimum 20mm clearance below valve for exhaust dispersion.
Use ISO 8573-1 Class 3.4.2 compressed air (max particle size 5μm, oil content ≤1mg/m³).
| Property | Property Value |
|---|---|
| sku | 2KWX03008B |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC24V |
