Airtac 2KWX Fluid Solenoid Valve 2KWX03008E
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX03008E Fluid Solenoid Valve Technical Details
- Model: 2KWX03008E
- Type: 3-position, 5-way (double solenoid) with spring centering
- Port size: PT3/8 (G3/8 ISO228-1 compliant)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±5% (excluding connectors)
- Dimensions: 108mm(L) × 54mm(W) × 89mm(H)
- Body material: Die-cast aluminum alloy with hard anodized finish
- Seal compounds: HNBR (Hydrogenated Nitrile) for high temp/petrochemical resistance
- Temperature tolerance: -10℃ to 120℃ (ambient/fluid)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤25ms (energize), ≤15ms (de-energize) @ 0.5MPa
- Flow capacity: 750 NL/min (Cv=1.2) @ 0.5MPa
- Protection class: IP67 (dust/immersion resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with dual coil redundancy, engineered for precision directional control in industrial automation. Features surge-protected coils (1000V/1s impulse withstand) and manual override capability. Requires 5μm filtration with automatic drain for optimal performance.
- Plastic injection molding machine hydraulic circuits
- Automated assembly line clamping/positioning systems
- CNC machine tool coolant flow management
- Food processing pneumatic actuators (NSF-H1 grease compatible)
- Electric vehicle battery cooling systems
Mounting protocol:
Install with vibration-damping brackets in horizontal orientation.
Maintain 15mm clearance from adjacent components for heat dissipation.
Pre-charge system with 0.05MPa pressure before full activation.
| Property | Property Value |
|---|---|
| sku | 2KWX03008E |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | AC24V |
