Airtac 2KWX Fluid Solenoid Valve 2KWX03008F
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX03008F Fluid Solenoid Valve Specifications
- Model: 2KWX03008F
- Type: 2-position, 3-way (3/2) normally closed direct-acting
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.3
- Max flow rate: 800 L/min (ANR)
- Response time: ≤15ms (on/off)
- Seal material: Heat-resistant NBR (Nitrile), optional FKM available
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Power consumption: 2.8W (DC models), 4.5VA (AC models)
- Protection rating: IP67 (dustproof and waterproof)
- Electrical connection: DIN43650 Form A connector
- Weight: 310g ±5g
- Dimensions: 53mm(W) × 40mm(H) × 78mm(L)
The 2KWX03008F features an optimized magnetic circuit design for rapid response and low energy consumption. Its corrosion-resistant brass body and hardened stainless steel core tube ensure durability in humid environments. The valve supports manual override capability via push-button operation and includes built-in surge protection for enhanced electrical safety.
- Industrial automation assembly line controls
- Beverage dispensing systems requiring frequent actuation
- Textile machinery air circuit management
- Medical gas control systems (oxygen/nitrogen)
- Semiconductor manufacturing equipment
Installation guidelines:
Mount in vibration-free environments using M4 screws (max torque 1.2N·m).
Always install downstream filter (5μm minimum) and lubricator when used with pneumatic tools.
For horizontal mounting, orient coil connector upward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | 2KWX03008F |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC12V |
