Airtac 2KWX Fluid Solenoid Valve 2KWX05010A
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX05010A Fluid Solenoid Valve Specifications
- Model: 2KWX05010A
- Type: 5/2-way monostable (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 320g ±5g (with coil)
- Dimensions: 62mm(L) × 42mm(W) × 75mm(H)
- Port thread depth: 10mm (4 effective threads)
- Seal material: FKM (Fluorocarbon Rubber) standard (NBR optional)
- Temperature range: -5℃ to 80℃ (no freeze)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Max flow rate: 850 L/min (ANR)
- Service life: ≥10 million cycles (at rated conditions)
High-flow proportional control valve with dual-color LED status indicator (red/green). Features brass main body with chrome-plated spool for corrosion resistance. Compatible with ISO 15407-1 standards, designed for precision air flow regulation in industrial automation. Requires 5μm filtered dry air with oil mist ≤1mg/m³.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers and spindle brakes
- Beverage filling station pneumatic circuits
- Textile machinery tension control systems
Installation notes:1. Mount in vibration-free environment (max 1.5G vibration)
2. Maintain ≥50mm clearance below valve for maintenance access
3. Use M3x8 stainless screws (1.2-1.5N·m torque)
4. Pre-charge system with 0.3MPa air before initial activation
| Property | Property Value |
|---|---|
| sku | 2KWX05010A |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
