Airtac 2KWX Fluid Solenoid Valve 2KWX05010E
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX05010E Fluid Solenoid Valve Technical Details
- Model: 2KWX05010E
- Valve type: 2-position, 5-port (5/2-way) direct-acting
- Port size: G1/8 (ISO228/1 standard)
- Operation mode: Double solenoid (dual coil) or single solenoid with spring return
- Working medium: Compressed air (non-lubricated, oil-free)
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Flow coefficient (Cv): 1.8
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (Nitrile) for -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Protection class: IP67 (dustproof & waterproof)
- Port thread depth: 10mm (minimum engagement)
- Weight: 480g ±5% (with coils)
- Dimensions: 56mm(W) × 47mm(H) × 102mm(L)
- Compliance: RoHS 2.0, REACH
High-flow proportional control valve with optimized spool structure for precise air distribution. Features anti-vibration design for industrial environments and low-hysteresis operation. Requires 5-40μm filtration with maximum 0.1mg/m³ oil content. Manual override option available (rotary type).
- Automated assembly line clamping systems
- Textile machinery air circuit control
- Plastic injection molding machine actuators
- CNC tool changers and spindle brakes
- Semiconductor wafer handling robots
Installation guidelines:
Mount in vibration-free area using M5 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance below valve for heat dissipation. Lubricate seals
with ISO VG32 hydraulic oil if used in high-cycle applications (>5Hz).
| Property | Property Value |
|---|---|
| sku | 2KWX05010E |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
