Airtac 2KWX Fluid Solenoid Valve 2KWX05010F
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX05010F Fluid Solenoid Valve Specifications
- Model: 2KWX05010F
- Type: 2-position 5-port direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC220V (50/60Hz)
- Weight: 680g ±5% (including coil)
- Dimensions: 80mm(L) × 60mm(W) × 120mm(H)
- Seal material: NBR (standard), FKM available for high-temp
- Temperature range: -20℃ to 80℃ (NBR seals)
- Power consumption: DC: 3.5W / AC: 4.2VA
- Response time: ≤30ms (at 0.5MPa)
- Port thread depth: 12mm (full thread engagement)
- Protection rating: IP67 (coil)/IP65 (valve body)
- Max flow rate: 750 L/min (Cv=1.8)
High-flow solenoid valve with direct drive mechanism for precise fluid control in medium-pressure systems. Features brass main body with chrome-plated spool for corrosion resistance. Compatible with compressed air, water, and light oils (ISO VG32 or lower). Requires 5μm filtration for optimal performance.
- Industrial automation pneumatic circuits
- Beverage dispensing systems
- Textile machinery fluid control
- Semiconductor cooling water systems
- Medical gas control panels
- Packaging machine actuator control
Installation notes:1. Mount in any orientation (horizontal recommended for drainage)
2. Use flexible tubing for vibration isolation
3. Replace seals every 5 million cycles (NBR) or 8 million cycles (FKM)
4. Maintain 15mm clearance for coil heat dissipation
Avoid using with:- Phosphate ester fluids
- Media containing solid particles >5μm
- Continuous duty cycles exceeding 90% ON time
| Property | Property Value |
|---|---|
| sku | 2KWX05010F |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
