Airtac BSE Clamp Standard Cylinder BSE32X1000S
The AirTAC Airtac BSE Clamp Standard Cylinder BSE32X1000S is a genuine double-acting ISO 15552 cylinder with an integrated spring-applied, air-released ROD LOCK. If air is cut or an E-stop is hit, the collet clamps the Ø12mm rod and holds up to 600 N in either direction — no drift. Ø32mm bore, 1000mm stroke, PT1/8 cylinder ports, G1/8 lock-release port.
- BoreØ32 mm
- Stroke1000 mm
- Static holding force600 N
- Lock typeSpring-lock / air-release
- Cylinder portPT1/8
- Lock-release portG1/8
About the Airtac BSE Clamp Standard Cylinder BSE32X1000S
The AirTAC BSE32X1000S is a double-acting ISO 15552 profile cylinder featuring an integrated spring-applied, air-released rod lock. A collet clamps the Ø12 mm piston rod, delivering a 600 N bidirectional static holding force with zero live air required. If air pressure drops or an E-stop trips, the lock engages fail-safe to prevent drift.
Operating pressure is capped at 0.15-0.7 MPa, and the lock unlocks via a separate G1/8 port. The 1000 mm stroke exceeds the 700 mm standard maximum, making this a made-to-order unit. The -S option includes a magnet for CMSE reed or DMSE electronic sensors. Remember the lock is a holding device, not a dynamic brake; engage it only after the rod fully stops.
Rod Lock — 600 N Static Holding (Ø32mm)
A spring clamps the collet onto the rod, so the Airtac BSE Clamp Standard Cylinder BSE32X1000S holds its position in both directions when air is lost, exhausted or an E-stop trips. Apply 0.15–0.7 MPa to the G1/8 release port to unlock. Engage the lock only after the rod has stopped (it is not a dynamic brake), and release only when the pressures on both sides of the piston are balanced. Allow at least 0.5 s for full release before moving.
Airtac BSE Clamp Standard Cylinder BSE32X1000S Technical Specifications
| Model | Airtac BSE Clamp Standard Cylinder BSE32X1000S |
|---|---|
| Series | BSE ISO 15552 rod-lock cylinder |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Static holding force | 600 N |
| Cylinder port | PT1/8 |
| Lock-release port | G1/8 |
| Rod thread | M10×1.25 |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Unlocking pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 700 mm |
Specifications follow the official AirTAC BSE datasheet. The lock uses the SE standard body; SE mounting accessories fit BSE except FTC. Port options: PT (standard) / G (BSPP); lock-release port is G1/8.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa (max) | 563 N | — |
| Max drive (@0.7 MPa) | 57 kgf | |
Drive force is separate from the 600 N static holding force of the lock. BSE operates up to 0.7 MPa. Size with a safety margin.
Model Code: Airtac BSE Clamp Standard Cylinder BSE32X1000S
| B | Rod-lock cylinder prefix. |
|---|---|
| SE | ISO 15552 standard double-acting body. |
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Thread: PT (blank) / G. Mounting (BSE): Basic, LB, FA, FB, CA, CB, CR, TC (FTC is not available on BSE). Related: SE (no lock), BSED (double-rod rod lock). Sensors CMSE/DMSE fit magnetic BSE.
Where the Airtac BSE Clamp Standard Cylinder BSE32X1000S Is Used
Z-Axis Elevator Hold
Secures a vertical lifting stage on a packaging machine. The 600 N fail-safe collet prevents the 1000 mm rod from drifting downward under gravity during an air loss event.
Tooling Drop Prevention
Clamps a pneumatic machining head. If air exhausts unexpectedly, the spring-applied lock holds the tooling rigidly in place, protecting the workpiece from a crash.
Access Gate Lock
Holds a long-stroke safety gate open on a conveyor line. The lock keeps the gate fixed during an E-stop until the system is deliberately reset and cleared.
Is the Airtac BSE Clamp Standard Cylinder BSE32X1000S the Right Cylinder?
Verify your suspended load requires less than the 600 N static holding force. If you need less drive force, the adjacent 32 mm bore is the smallest available. If you need more holding or drive capacity, step up to the 40 mm bore, which provides 628 N push at 0.5 MPa and 900 N of holding force.
Because this 1000 mm stroke is non-standard and made-to-order, carefully manage side loads using a guide to prevent rod binding. When ordering a replacement, match the 32 mm bore, 1000 mm stroke, PT1/8 cylinder port, and -S magnet. All SE mounting accessories fit this body except FTC. To release the lock safely, balance pressures on both sides of the piston and allow at least 0.5 s before moving.
Quick checklist
- ✓ Load to hold ≤ 600 N?
- ✓ Fail-safe hold on air loss / E-stop needed
- ✓ Lock engaged only when stopped
- ✓ G1/8 release-air line available
- ✓ Magnet (-S) for CMSE/DMSE sensors?
Installation & Safety Notes
- check Engage the lock only after the rod has stopped — not as a dynamic brake.
- check Release only when both piston sides are pressure-balanced.
- check Allow ≥0.5 s for full release before commanding motion.
- check Feed the G1/8 release port with 0.15–0.7 MPa clean air.
- check Add safety-rated controls for man-rated / overhead loads.
- check Use SE mounting accessories (FTC excepted).
Airtac BSE Clamp Standard Cylinder BSE32X1000S FAQ
The drive force at 0.5 MPa is 402 N push and 345 N pull. At the 0.7 MPa maximum operating pressure, push is 563 N (max 57 kgf). The integrated rod lock provides a separate 600 N static holding force.
The lock is spring-applied and fail-safe. If air is lost or exhausted, a collet clamps the rod to hold it bidirectionally at its stopped position. It is not a dynamic brake; you must engage it only after the rod stops, and release it only when piston pressures are balanced with at least 0.5 s delay.
