Airtac BSE Clamp Standard Cylinder BSE32X100
The AirTAC Airtac BSE Clamp Standard Cylinder BSE32X100 is a genuine double-acting ISO 15552 cylinder with an integrated spring-applied, air-released ROD LOCK. If air is cut or an E-stop is hit, the collet clamps the Ø12mm rod and holds up to 600 N in either direction — no drift. Ø32mm bore, 100mm stroke, PT1/8 cylinder ports, G1/8 lock-release port.
- BoreØ32 mm
- Stroke100 mm
- Static holding force600 N
- Lock typeSpring-lock / air-release
- Cylinder portPT1/8
- Lock-release portG1/8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac BSE Clamp Standard Cylinder BSE32X100
The AirTAC BSE32X100 is a double-acting ISO 15552 profile cylinder with an integrated spring-applied, air-released rod lock. It delivers a 600 N bidirectional static holding force with no live air, running at a 0.15-0.7 MPa operating pressure ceiling.
The lock uses a clamping collet engaged by spring force, released via a separate G1/8 port. This SKU has no magnet, meaning CMSE or DMSE position sensors cannot be used. SE mounting accessories fit this body, except for FTC.
Rod Lock — 600 N Static Holding (Ø32mm)
A spring clamps the collet onto the rod, so the Airtac BSE Clamp Standard Cylinder BSE32X100 holds its position in both directions when air is lost, exhausted or an E-stop trips. Apply 0.15–0.7 MPa to the G1/8 release port to unlock. Engage the lock only after the rod has stopped (it is not a dynamic brake), and release only when the pressures on both sides of the piston are balanced. Allow at least 0.5 s for full release before moving.
Airtac BSE Clamp Standard Cylinder BSE32X100 Technical Specifications
| Model | Airtac BSE Clamp Standard Cylinder BSE32X100 |
|---|---|
| Series | BSE ISO 15552 rod-lock cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Static holding force | 600 N |
| Cylinder port | PT1/8 |
| Lock-release port | G1/8 |
| Rod thread | M10×1.25 |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Unlocking pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 700 mm |
Specifications follow the official AirTAC BSE datasheet. The lock uses the SE standard body; SE mounting accessories fit BSE except FTC. Port options: PT (standard) / G (BSPP); lock-release port is G1/8.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa (max) | 563 N | — |
| Max drive (@0.7 MPa) | 57 kgf | |
Drive force is separate from the 600 N static holding force of the lock. BSE operates up to 0.7 MPa. Size with a safety margin.
Model Code: Airtac BSE Clamp Standard Cylinder BSE32X100
| B | Rod-lock cylinder prefix. |
|---|---|
| SE | ISO 15552 standard double-acting body. |
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Thread: PT (blank) / G. Mounting (BSE): Basic, LB, FA, FB, CA, CB, CR, TC (FTC is not available on BSE). Related: SE (no lock), BSED (double-rod rod lock). Sensors CMSE/DMSE fit magnetic BSE.
Where the Airtac BSE Clamp Standard Cylinder BSE32X100 Is Used
Small Vertical Lifts
Holds 600 N static loads on small vertical actuators if air pressure drops, preventing sudden descent of light platens.
Tooling Clamp
Maintains clamping force on machined parts during an E-stop, keeping the workpiece secure with no live air required.
Gate Stop
Locks a conveyor diverter gate in the exact stopped position, resisting bidirectional vibration until the G1/8 release port is pressurized.
Is the Airtac BSE Clamp Standard Cylinder BSE32X100 the Right Cylinder?
Verify your load stays under the 600 N holding force. If you need less force, no smaller BSE bore exists. If you need more, step up to bore 40, which gives 628 N push at 0.5 MPa and a 900 N hold. Engage the lock only after the rod fully stops, and allow at least 0.5 s for release after balancing piston pressures. This 100 mm stroke is short, so side-load guides are less critical here. Match the 32 mm bore, 100 mm stroke, PT1/8 port, and basic mounting for replacements.
Quick checklist
- ✓ Load to hold ≤ 600 N?
- ✓ Fail-safe hold on air loss / E-stop needed
- ✓ Lock engaged only when stopped
- ✓ G1/8 release-air line available
- ✓ Magnet (-S) for CMSE/DMSE sensors?
Installation & Safety Notes
- check Engage the lock only after the rod has stopped — not as a dynamic brake.
- check Release only when both piston sides are pressure-balanced.
- check Allow ≥0.5 s for full release before commanding motion.
- check Feed the G1/8 release port with 0.15–0.7 MPa clean air.
- check Add safety-rated controls for man-rated / overhead loads.
- check Use SE mounting accessories (FTC excepted).
Airtac BSE Clamp Standard Cylinder BSE32X100 FAQ
The drive force is 402 N push and 345 N pull at 0.5 MPa, or 563 N push at 0.7 MPa (max 57 kgf). The separate static holding force of the rod lock is 600 N.
It is fail-safe: a spring applies a clamping collet to hold the rod bidirectionally at 600 N. To release, supply 0.15-0.7 MPa to the G1/8 port after balancing piston pressures, allowing 0.5 s before moving.
