Airtac F-TMIC Separate Guide Bracket F-TMICL16X25
$76.73
Regular price
$84.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TMICL16X25
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The guide unit-integrated cylinder represents an innovative design combining a guide mechanism with a pneumatic cylinder;
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
Installation note:
Apply lithium-based grease to rollers during assembly.
Use 4.8-grade mounting screws torqued to 1.2N·m ±10%.
Avoid direct exposure to cutting fluids without protective covers.
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL16X25 Linear Guide Bracket Specifications
- Model: F-TMICL16X25
- Type: Independent linear guide carriage
- Rail width: 16mm
- Block length: 25mm
- Material: Aluminum alloy (anodized surface)
- Static load capacity: 1,200N (radial), 600N (lateral)
- Dynamic load rating: 800N (radial), 400N (lateral)
- Precision grade: Normal (C) / High (H) optional
- Sealing type: Double-lip contact seals
- Temperature range: -10℃ to 80℃
- Surface hardness: HV400±15%
- Weight: 0.45kg ±5%
- Dimensions: 25mm(L) × 16mm(W) × 10mm(H)
- Mounting hole pattern: 4×M4 threaded holes (pitch 18mm)
Precision-engineered linear motion component with hardened steel rollers and corrosion-resistant aluminum body. Features integrated sealing for dust protection and pre-loaded adjustment mechanism (0.02-0.05mm clearance). Compatible with standard 16mm linear rails.
Typical Applications:
- CNC router Z-axis guidance systems
- Automated packaging line conveyors
- 3D printer gantry alignment
- Medical imaging equipment slides
- Semiconductor wafer handling robots
Installation note:
Apply lithium-based grease to rollers during assembly.
Use 4.8-grade mounting screws torqued to 1.2N·m ±10%.
Avoid direct exposure to cutting fluids without protective covers.
| Property | Property Value |
|---|---|
| sku | F-TMICL16X25 |
| Bore Diameter | 16mm |
| Bearing Category | Linear Bearing |
