Airtac F-TMIC Separate Guide Bracket F-TMICM16X50
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICM16X50 Individual Guide Bracket Specifications
- Model: F-TMICM16X50
- Type: Linear motion guide support unit
- Mounting Thread: M16×1.5 (metric fine thread)
- Effective Length: 50±0.1mm
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Surface Hardness: HRC 58-62
- Load Capacity (Dynamic): 1,200N radial / 600N axial
- Load Capacity (Static): 2,400N radial / 1,200N axial
- Precision Grade: P5 (ISO 492 Class 5)
- Operating Temperature: -20℃ to 120℃
- Surface Treatment: Black oxide coating (5-8μm)
- Weight: 450g ±2%
- Dimensions: 50mm(L) × 32mm(W) × 24mm(H)
- Mounting Hole Pattern: 60mm × 40mm rectangular array
- Runout Tolerance: ≤0.015mm
Precision-machined guide bracket with integrated preloaded ball bearings, designed for high-rigidity linear motion systems. Features corrosion-resistant black oxide coating and dual-row angular contact bearing configuration for simultaneous radial and axial load handling. Includes anti-vibration mounting pads and alignment marks for simplified installation.
- CNC machine tool Z-axis support systems
- Automated optical inspection (AOI) equipment stages
- Semiconductor wafer handling robots
- High-speed packaging line linear actuators
- Precision 3D printing gantry systems
Installation note:
Apply 80-100N·m torque during mounting. Use dial indicator to verify ≤0.02mm parallelism
between bracket base and machine bed. Requires periodic lubrication with ISO VG32-grade
machine oil every 500 operating hours.
| Property | Property Value |
|---|---|
| sku | F-TMICM16X50 |
| Bore Diameter | 16mm |
| Bearing Category | Bronze Bushing |
