Airtac F-TMIL Guide Unit Assembly F-TMIL12X100
2. Sliding bushings: Ideal for applications requiring radial load resistance such as braking operations, offering enhanced torsional rigidity; Linear bushings: Suitable for pushing/lifting actions, high-precision scenarios, and heavy-load applications, particularly optimized for low-friction movement requirements;
3. Specially engineered guide unit body enables multi-directional mounting configurations for flexible installation.
Category: Guide Units | Brand: AirTAC | Series: F-TMIL
AirTAC F-TMIL12X100 Linear Guide Bracket Complete Package Specifications
- Model: F-TMIL12X100
- Type: Linear motion guide assembly with integrated support
- Bore diameter: 12mm (precisely honed)
- Rod compatibility: 12mm diameter linear shafts
- Effective stroke: 100mm (±0.5mm tolerance)
- Material: Aluminum alloy (AL6063-T5) with hard anodized surface
- Static load capacity: 1,200N radial / 600N axial
- Dynamic load rating: 800N radial / 400N axial
- Mounting hole pattern: 50mm × 30mm (M5 threaded holes)
- Surface hardness: HV400-450
- Operating temperature: -20℃ to 120℃
- Weight: 285g ±5g (including all mounting hardware)
- Dimensions: 150mm(L) × 42mm(W) × 38mm(H)
- Wear resistance: ≤0.01mm/100km (under standard load)
- Included components: Bracket body, precision guide bushings (2 pcs), mounting screws (4 pcs M5×10), dust seals
Precision-engineered linear motion solution combining rigid bracket structure with low-friction bushings, designed for repeatable linear movements in industrial automation. Features dual-layer chromium-plated guide rods (optional) and anti-creep locking collars. Pre-lubricated with MIL-SPEC grease for maintenance-free operation up to 5,000 cycles.
- CNC machine tool axis stabilization systems
- Automated packaging equipment sliding mechanisms
- 3D printer gantry alignment systems
- Semiconductor wafer handling robots
- Medical imaging device positioning arms
Installation note:
Align within 0.05mm/m parallelism tolerance during mounting.
Apply 2.5-3.5N·m torque to M5 fasteners using Loctite 243 threadlocker.
Avoid side impact loads exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | F-TMIL12X100 |
| Bore Diameter | 12mm |
| Stroke | 100mm |
