AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally open
- Port size1/8 in
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W)
The 3V11006NOBG-W is a 3/2 solenoid valve with three ports - supply, outlet and exhaust - and two states. This one is normally open: at rest the outlet is fed from the supply, and energising the coil shuts off the supply and vents the outlet to exhaust. That reverse behaviour is what a blow-off, a dump function or a spring-return cylinder that must stay extended on power loss calls for.
It is a genuine AirTAC part in the 3V1 family, fitted with a 1/8in PT port, a DC24V coil and a DIN plug connection. The same family also covers normally closed versions, five coil voltages, flying-lead entry and 3V-F manifold bases. Pressure, flow and coil-power figures are not published on this page; send the model to us and we will read them out of the AirTAC datasheet for you.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally open |
| Port size | 1/8 in |
| Thread | G (BSPP parallel) |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NO | Normally open: air passes until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| G (BSPP parallel) | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W) Is Used
Fixture clamp on a milling machine
A spring-return clamp that must stay gripped through a control power dip: at rest the normally open valve keeps air on the single-acting cylinder, and energising the coil dumps the clamp.
Chip blow-off at a CNC machining centre
An air nozzle that clears swarf between cuts. The NO state holds the jet fed while the machine idles, and the controller cuts it by energising the coil.
Piloting a large diaphragm process valve
A 1/8in signal valve is a classic pilot stage: this one vents the pilot line of a much larger main valve when energised, letting the spring close the main valve.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W) the Right Part?
Choose NO when the desired rest condition is air at the outlet: a normally closed valve gives nothing downstream until energised, while a normally open one keeps feeding until told to stop. The DC24V coil must sit on a 24 volt DC supply - coil voltage is fixed at the factory and cannot be changed by rewiring, so match it to the panel before ordering. The DIN plug seats into a standard connector on the valve body; if you would rather have pre-wired leads, the same valve exists with an I suffix. PT is the standard thread on this family, with G and NPT as catalogue options to order. On sizing: we do not hold published flow figures for the 3V1 bodies, so ask us to check the valve against your actuator before you commit. If you need a 3-port valve with published flow and coil power today, the AirTAC 3V2 (1/8in and 1/4in) and 3V3 (1/4in) are the documented alternatives.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOBG-W) FAQ
We do not publish them on this page. Tell us your supply pressure and actuator and we will confirm the figures from the AirTAC datasheet on request. If you need numbers published up front, the AirTAC 3V2 and 3V3 bodies are the ones with documented flow and coil-power figures.
No. A 3/2 valve has only one outlet, so it can feed or vent a single-acting, spring-return cylinder or a blow point, but it cannot push and pull a double-acting cylinder. For that you need a 5-port valve such as the AirTAC 4V series.
