Airtac 3V200 Solenoid Valve 3V21006NCAI
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V210-06NC-AI Solenoid Valve Specifications
- Full model code: 3V21006NCAI (standardized as 3V210-06NC-AI)
- Valve type: 3/2-way normally closed, pilot-operated with manual override
- Port thread: PT1/8" (G1/8 optional, specify when ordering)
- Operating pressure range: 0.05–1.0 MPa (minimum startup pressure 0.15 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: DC: 1.6W / AC: 2.5VA
- Flow capacity: CV 0.14 (Kv 0.12) at 0.5MPa
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Seal material: High-grade NBR (Nitrile) with PTFE backup rings
- Valve body material: Anodized aluminum alloy (AL6063-T5)
- Operating temperature: -20℃ to +80℃ (with 5℃ safety margin)
- Protection rating: IP67 (dustproof & temporary immersion protection)
- Weight: 168g ±3g (including coil and accessories)
- Dimensions: 48mm(L) × 32mm(W) × 62mm(H) (excluding fittings)
- Port axis configuration: Inlet(P) - Bottom, Outlet(A) - Side, Exhaust(R) - Rear
This high-cycle valve features a dual-coil heat dissipation design with surge protection diodes, optimized for rapid switching in compact pneumatic systems. The hardened stainless steel plunger and precision lapped guide sleeves ensure 10 million+ cycles MTBF. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (40μm filtration, dew point -20℃).
- High-speed pick-and-place robotics (cycle times <0.5s)
- CNC machine tool coolant line control
- Lithium battery production line vacuum gripper systems
- Food-grade pneumatic actuators (NSF-compliant version available)
- Outdoor HVAC damper control with surge protection
Maintenance protocol:
For continuous duty cycles exceeding 60% ON-time, implement forced-air cooling (0.3m/s minimum airflow)
and inspect seals every 500k cycles. Lubrication not required - use only dry air supply.
- Optimal with ATC-10 series quick connectors
- Use APV-06M silencers for noise-sensitive environments
- Pair with APE-08 pressure sensors for closed-loop control
| Property | Property Value |
|---|---|
| sku | 3V21006NCAI |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
