Airtac 3V300 Solenoid Valve 3V31008NCAT-W
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCAT-W Technical Details
- Model Decode: 3V300-10-NC-AT-W
- 3V300: Series code for mid-flow valves
- 10: Port size code (PT3/8 equivalent)
- NC: Normally closed configuration
- A: AC voltage variant
- T: With manual override
- W: Weather-resistant version
- Valve type: 3/2-way pilot-operated (indirect acting)
- Port thread: PT3/8 (G3/8 optional)
- Effective area ratio: 1:1.15 (pilot to main valve)
- Operating pressure range: 0.15–1.0 MPa (extended range)
- Voltage specifications:
- AC: 100V 50/60Hz (±10%), 200V 50/60Hz (±10%)
- DC: 24V (±10%) with surge protection
- Flow capacity: 1600 l/min (Cv=1.8 at 0.5MPa)
- Response time: ≤25ms (exhaust to actuation)
- Seal materials:
- Main seal: HNBR (Hydrogenated Nitrile)
- Secondary seals: FKM (Fluorocarbon)
- Core tube: SUS304 stainless steel
- Temperature tolerance: -25℃ to 80℃ (with 5℃ buffer at extremes)
- Durability: ≥10 million cycles (JIS B8377 standard)
- Weight: 320g ±5% (with mounting bracket)
- Dimensions: 58mm(L) × 36mm(W) × 72mm(H) (including pneumatic ports)
- Protection features: IP67 (submersible up to 1m), surge absorber integrated
- Compliance: RoHS 3, REACH SVHC 239 substances
High-flow industrial solenoid valve with anti-vibration design, featuring a dual-chamber structure that prevents pressure locking. The tungsten carbide plunger ensures stable operation in high-cycle applications (up to 5Hz). Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.2.2 air quality. Includes built-in LED status indicator with overcurrent protection.
- Plastic injection molding machine ejectors
- CNC tool changers with high-speed actuation
- Semiconductor wafer handling robots
- Food processing pneumatic lines (NSF compliant version available)
- Railway braking test systems
Installation protocol:
Mount with vibration-damping gaskets (not included). For horizontal mounting,
use port-down orientation. Allow 15mm clearance for heat dissipation during
continuous duty cycles. Lubrication-free operation - do not apply grease to
sliding surfaces.
| Property | Property Value |
|---|---|
| sku | 3V31008NCAT-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
