Airtac 3V300 Solenoid Valve 3V31008NCBG-W
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCBG-W Technical Profile
- Full model designation: 3V31008NCBG-W (3V300 platform)
- Valve configuration: 3/2-way normally closed (pilot-operated)
- Port threading: PT1/4 (G1/4 BSPP standard)
- Pressure operating range: 0.15–1.0 MPa (extended upper limit)
- Voltage variants: DC12V/24V, AC110V/120V/220V/240V (50/60Hz compatible)
- Flow capacity: Cv=0.25 (Kv=0.23) @7bar
- Response time: ≤20ms open/close (at rated voltage)
- Seal compound: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Ambient temperature: -10℃ to 80℃ (derating required above 50℃)
- Coil insulation class: Class F (155℃ maximum)
- Power consumption: 1.8W (DC)/3.5VA (AC)
- Protection standard: IP67 (dust/immersion protected)
- Weight: 320g ±5% (with bracket)
- Dimensions: 52mm(L) × 38mm(W) × 70mm(H) (excluding connectors)
- Port alignment: ISO 15407-1 compliant
- Manual override: Optional mechanical button (suffix "-M")
High-flow industrial solenoid valve with reinforced epoxy coil housing and corrosion-resistant anodized aluminum body. Features shock/vibration tolerance up to 10G (1hr) and built-in surge protection circuitry. Requires 5μm filtered air with lubricant-free or ISO VG32 turbine oil mist (≤1/40,000 concentration).
- High-cycle pneumatic presses (＞500k cycles/month)
- CNC machine tool clamping systems
- Plastic injection molding ejectors
- Bottle filling line diverters
- Lithium battery production automation
- Railway brake test benches
Installation protocol:
Mount with 10Nm torque limit on mounting screws. Maintain ≥15mm clearance
from high-frequency inverters. Use copper shielding conduit for power lines
in EMI-intensive environments. Perform monthly manual cycling if idle periods
exceed 30 days.
- AirTAC SCPF-04D filter regulator (for micro-particle control)
- Mounting base VF300-4G (for manifold integration)
- LED diagnostic kit AD48-01 (voltage status indication)
| Property | Property Value |
|---|---|
| sku | 3V31008NCBG-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
