Airtac 3V300 Solenoid Valve 3V31008NCBI-W
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCBI-W Technical Details
- Full model designation: 3V31008NCBI-W
- Valve type: 3-way (3V3), 2-position direct-acting with manual override
- Port configuration: 3 ports (P: pressure, A: outlet, R: exhaust)
- Operation mode: Normally closed (NC)
- Port thread size: PT1/4 (BSPP) with ISO G1/4 optional
- Operating pressure range: 0.1-1.0 MPa (14.5-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Flow coefficient (Cv): 1.6 (at 7 bar)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: High-grade HNBR rubber (-20℃ to 120℃)
- Body material: Reinforced PBT with UL94 V-0 flame rating
- Protection rating: IP67 (dustproof & temporary immersion)
- Weight: 220g ±5% (including coil)
- Dimensions: 55mm (L) × 35mm (W) × 70mm (H)
- Mounting orientation: Any (360° rotatable coil)
High-flow compact solenoid valve featuring dual-chamber design for enhanced pressure balancing. The 3V31008NCBI-W incorporates a copper-free aluminum alloy piston and gold-plated terminals for corrosion resistance in humid environments. Its low-hysteresis coil (Class F insulation) ensures stable operation with 100% ED (continuous duty) capability. Requires 5μm filtration with oil mist lubrication (ISO VG32 recommended).
- Pneumatic cylinder sequencing in assembly robots
- Vacuum generator control for material handling systems
- Coolant line switching in CNC machining centers
- Packaging machine clamp/unclamp operations
- Medical gas distribution equipment
Operational note:
Maintain air quality per ISO 8573-1:2010 Class 3.4.2 (max particle size 5μm,
pressure dew point 3℃ below minimum operating temperature). For horizontal
piping, install valve with exhaust port downward to prevent condensate ingress.
| Property | Property Value |
|---|---|
| sku | 3V31008NCBI-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
