Airtac B06-MAC Battery-Specific Cylinder B06-MAC16X20SCM
AirTAC B06-MAC16X20SCM Battery-Powered Cylinder Specifications
- Model: B06-MAC16X20SCM
- Type: Double-acting battery-operated cylinder with magnetic piston
- Bore size: 16mm
- Stroke: 20mm
- Mounting style: SCM (Compact side-mount bracket)
- Material: Aluminum alloy barrel, stainless steel piston rod
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable rubber cushion at both ends
- Position sensing: Built-in magnet for proximity sensor detection
- Sensor compatibility: NPN/PNP inductive sensors (not included)
- Battery compatibility: 12-24V DC (Li-ion/NiMH battery systems)
- Weight: 0.68kg (including mounting hardware)
- Dimensions: 135mm(L) × 42mm(W) × 42mm(H)
- Temperature range: -10℃ to 60℃
- Seal material: Heat-resistant NBR with low friction coefficient
- Protection rating: IP54 (standard), IP67 optional
- Cycle life: ≥2,000km (under rated pressure)
Compact energy-saving pneumatic actuator designed for battery-dependent mobile automation systems. Features integrated power optimization circuitry reducing standby consumption by 40% compared to standard models. The SCM mounting configuration enables direct installation in space-constrained environments while maintaining structural rigidity.
- AGV (Automated Guided Vehicle) lifting mechanisms
- Portable medical equipment actuators
- Solar-powered agricultural gate controls
- Mobile robotic arm end-effectors
- Battery-operated packaging line diverters
Operational note:
Requires periodic lubrication (every 500km stroke) with ISO VG32-grade pneumatic oil.
For battery systems, maintain voltage above 10.5V DC to ensure consistent magnetic
coupling efficiency. Avoid continuous duty cycles exceeding 60s without rest period.
