Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA
The AirTAC Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA is a genuine double acting + cushion standard round-body mini air cylinder with a Ø0mm bore and 350mm stroke, PT/G air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ0 mm
- Stroke350 mm
- Port sizePT/G
- Acting typeDouble acting + cushion
- Rod thread
- CushionVariable air cushion, both ends
About the Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA
With a CA pivot eye in the back cover, the MAC32X350SCA follows the arc of swinging gates and tilting lids over a 350 mm stroke. It is double acting with a variable air cushion at each end, and at 0.5 MPa delivers 402 N out and 346 N back.
Inside, a rolled stainless barrel grips the aluminium covers and the hard-chrome 12 mm rod resists corrosion without coatings to chip. For steady sizing, treat the rating as about 240 N of usable force at 0.5 MPa, and note the standard magnet already accepts CMSG, DMSG and EMSG switches for end-of-stroke signalling.
Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA Technical Specifications
| Model | Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA |
|---|---|
| Series | MAC mini cylinder |
| Bore size | Ø0 mm |
| Stroke | 350 mm |
| Acting type | Double acting + cushion |
| Port size | PT/G |
| Rod thread |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø0mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 0 N | 0 N |
| 0.7 MPa | 0 N | 0 N |
| Max (@1.0 MPa) | 0 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA
| MAC | Standard round-body mini cylinder (double-acting, variable cushion). |
|---|---|
| 0 | Bore size in mm. |
| ×350 | Stroke length in mm. |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA Is Used
Mixing vat lid tilt
Swings a stainless lid open on a food mixing vat; the CA pivot eye follows the arc so no extra linkage bracket is needed.
Reject chute swing gate
Deflects product flow into a reject lane on a snack line, and the 350 mm stroke clears the full belt width.
Drum lid clamp press
Pulls a clamp down over a 200 litre drum lid, using about 240 N of dependable force from the 402 N rating.
Is the Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA the Right Cylinder?
For lighter pivoting work the 25 mm bore manages 245 N at 0.5 MPa; for heavier swing gates step to 40 mm and its 628 N. This 32 mm model answers at 402 N with a CA eye ready to pin straight into your clevis, or choose FA flange, LB foot and SDB mounts to fix it solid. Without air the piston moves freely under load - the cushion is a shock damper, not a brake - so fit a rod lock or pilot check valve where a gate must stay open. At 350 mm reach, keep the pivot axis parallel to the rod plane or side bending will find the 12 mm chrome rod.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac B06-MAC Battery-Specific Cylinder B06-MAC32X350SCA FAQ
At 0.5 MPa: 402 N pushing, 346 N pulling. At 0.7 MPa push climbs to 563 N, and the theoretical peak is 82 kgf at 1.0 MPa. Operating window is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof and speeds of 30-800 mm/s.
No - every MAC32X350SCA ships with the magnet already built in, so CMSG, DMSG or EMSG reed and solid-state switches clip onto the 32 mm barrel at any point along the 350 mm stroke and are ready to signal end positions out of the box.
