Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA
The AirTAC Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA is a genuine double acting + cushion standard round-body mini air cylinder with a Ø0mm bore and 110mm stroke, PT/G air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ0 mm
- Stroke110 mm
- Port sizePT/G
- Acting typeDouble acting + cushion
- Rod thread
- CushionVariable air cushion, both ends
About the Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA
From AirTAC's MA family, the MAC50X110SCA is a double acting mini cylinder with a variable air cushion at both ends and a 110 mm stroke. Fed through 1/4" ports, the 50 mm bore pushes 981 N and pulls 881 N at 0.5 MPa, so it handles clamping, pushing and lifting jobs that smaller minis cannot.
The riveted round body pairs a stainless-steel barrel with a hard-chrome plated 16 mm rod, standing up to washdown and humid air far better than painted minis. Its CA pivot back cover takes a clevis directly, and the built-in magnet - standard, not an option - lets CMSG, DMSG or EMSG switches clip on for position signals. In practice, budget about 589 N of usable force at 0.5 MPa instead of the full 981 N rating.
Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA Technical Specifications
| Model | Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA |
|---|---|
| Series | MAC mini cylinder |
| Bore size | Ø0 mm |
| Stroke | 110 mm |
| Acting type | Double acting + cushion |
| Port size | PT/G |
| Rod thread |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø0mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 0 N | 0 N |
| 0.7 MPa | 0 N | 0 N |
| Max (@1.0 MPa) | 0 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA
| MAC | Standard round-body mini cylinder (double-acting, variable cushion). |
|---|---|
| 0 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA Is Used
Pallet stop lift
Raising lift-and-locate pins under a 110 mm conveyor lane; 981 N at 0.5 MPa carries pallet sections of about 50 kg vertically with margin.
Weld fixture clamp
Clamping brackets against a weld jig where the variable cushion stops the clamp arm slamming home at cycle speeds up to 800 mm/s.
Case pusher
Pushing filled cartons into a case packer or checkweigher; the pivot CA cover absorbs stroke alignment error from a clevis mount.
Is the Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA the Right Cylinder?
Compare both directions: the 40 mm bore gives 628 N push at 0.5 MPa, while the 63 mm bore reaches 1558 N - choose 50 mm when you need roughly a kilonewton class. Note that this cylinder drifts when air is lost or the valve centres; for a held position fit a rod lock or pilot check valve. Mount it pivoting with the CA back cover plus an SDB bracket or I/Y knuckle, or switch to FA flange or LB foot for fixed frames.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac B06-MAC Battery-Specific Cylinder B06-MAC50X110SCA FAQ
The 50 mm bore pushes 981 N and pulls 881 N at 0.5 MPa. At 0.7 MPa the figures rise to 1374 N push and 1233 N pull, and the theoretical maximum at 1.0 MPa is about 200 kgf. Pressure range is 0.15-1.0 MPa (22-145 psi) and speed 30-800 mm/s.
The stainless-steel barrel and hard-chrome plated rod resist corrosion in washdown, food and outdoor environments, and the riveted covers keep the joint sealed without tie rods. Air ports are 1/4", the rod is 16 mm with M14x1.5 male thread, and the cushion screws at both ends should be backed off and opened gradually on first run.
