This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ20X25-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10
The AirTAC Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 10 mm, giving a usable end-position window from 15 to 25 mm. This model is discontinued — the direct replacement is the MBLJ20X25-10.
- BoreØ20 mm
- Stroke25 mm
- Adjust window15–25 mm
- Port sizeG1/8
- Rod threadM8×1.25
- StatusDiscontinued → MBLJ20X25-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10
The AirTAC MALJ20X25-10 is a discontinued double-acting, double-rod mini cylinder featuring a rear adjustable stroke stopper. The -10 adjust code lets you trim up to 10 mm at the rear, creating a usable end-position window from 15 to 25 mm. The direct replacement is the MBLJ20X25-10, matching the 20 mm bore, 25 mm stroke, G1/8 port, and mounting footprint.
This SKU lacks the -S magnet option, so it cannot accept a position sensor. The original MALJ uses threaded covers and a fixed rubber bumper, whereas the MBLJ upgrade features a riveted rolling-packed body. Remember that the rear adjuster is a travel stop, not a lock; it sets the end position but will not hold a load without live air pressure.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10 Technical Specifications
| Model | Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ20X25-10 |
| Bore size | Ø20 mm |
| Stroke | 25 mm |
| Adjustable window | 15 – 25 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ20X25-10 carries the same ratings.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 132 N | 132 N |
| 0.7 MPa | 185 N | — |
| Max (@1.0 MPa) | 27 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ20X25-10 matches these values.
Model Code: Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 20 | Bore size in mm (20/25/32/40). |
| ×25 | Nominal stroke length in mm. |
| -10 | Adjustable amount: trim the end to a 15–25 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10 Is Used
PCB Depaneling Saw
Dial the 15-25 mm stroke window to set the exact blade clearance for routing populated circuit panels without repositioning the cylinder block.
Small Parts Ejector
Mounts on a packaging line to kick out lightweight plastic caps, using the fixed rubber bumper to soften the end-of-stroke impact.
Replacing the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10 with MBLJ20X25-10
To replace this MALJ20X25-10, order the exact direct replacement MBLJ20X25-10. Confirm the 20 mm bore, 25 mm stroke, 10 mm adjust code, G1/8 port, PT thread, and FA/LB mounting (no back cover or SDB is used). Because this SKU has no -S magnet, it cannot take a sensor; if you need a switch, the MBLJ replacement uses the newer CMSG/DMSG/EMSG family instead of the older CS1-M/DS1-M. The adjuster is a stop, not a lock.
For sizing, stepping down is not an option as 20 mm is the smallest available bore.
Upgrade checklist
- ✓ Order the MBLJ20X25-10 (same bore/stroke/adjust)
- ✓ Same 15–25 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ20X25-10 instead of this discontinued model.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-10 FAQ
Yes, the MALJ20X25-10 is discontinued. The direct replacement is the MBLJ20X25-10, which matches the 20 mm bore, 25 mm stroke, 10 mm adjust code, and G1/8 port. The MBLJ upgrades the body to a riveted rolling-packed design and uses CMSG/DMSG/EMSG sensors if you add a magnet.
The -10 adjust code lets you trim up to 10 mm at the rear, creating a usable stroke window from 15 to 25 mm.
