This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ20X25-20, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20
The AirTAC Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 20 mm, giving a usable end-position window from 5 to 25 mm. This model is discontinued — the direct replacement is the MBLJ20X25-20.
- BoreØ20 mm
- Stroke25 mm
- Adjust window5–25 mm
- Port sizeG1/8
- Rod threadM8×1.25
- StatusDiscontinued → MBLJ20X25-20
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20
The AirTAC MALJ20X25-20 is a discontinued double-acting mini cylinder with a 20mm bore and 25mm stroke. A rear stopper screw lets you trim the end position by up to 20mm, creating a usable 5-25mm stroke window. The direct replacement is the MBLJ20X25-20, matching the bore, stroke, G1/8 port, and mounting.
This SKU lacks a magnet (-S), so it cannot accept a position sensor. The adjuster is a travel stop, not a lock, and the fixed rubber bumper softens end impact without holding load. The original threaded covers are upgraded to a riveted rolling-packed body on the MBLJ20X25-20. Use it to fine-tune reach without adding external stops.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20 Technical Specifications
| Model | Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ20X25-20 |
| Bore size | Ø20 mm |
| Stroke | 25 mm |
| Adjustable window | 5 – 25 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ20X25-20 carries the same ratings.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 132 N | 132 N |
| 0.7 MPa | 185 N | — |
| Max (@1.0 MPa) | 27 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ20X25-20 matches these values.
Model Code: Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 20 | Bore size in mm (20/25/32/40). |
| ×25 | Nominal stroke length in mm. |
| -20 | Adjustable amount: trim the end to a 5–25 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20 Is Used
Connector Seating Jig
Fine-tune the downward reach on a manual connector seating jig, preventing damage to delicate pins by stopping the stroke early rather than relying on a lock.
Label Applicator Tamp
Adjust the tamp position on a small-batch label applicator, trimming the 25mm stroke to exactly match varying package heights without adding external mechanical stops.
Replacing the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20 with MBLJ20X25-20
Replace the MALJ20X25-20 with the direct replacement MBLJ20X25-20. Confirm the 20mm bore, 25mm stroke, 20mm adjust code, G1/8 port, and PT thread. Mounting is FA or LB only; there is no back cover or SDB option. Because this SKU lacks a magnet, it cannot take a sensor; the MBLJ20X25-20 without -S is identical.
As the smallest bore, the 20mm is the lower limit. Remember the adjuster sets end position but does not hold load without live air.
Upgrade checklist
- ✓ Order the MBLJ20X25-20 (same bore/stroke/adjust)
- ✓ Same 5–25 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ20X25-20 instead of this discontinued model.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X25-20 FAQ
Yes, the MALJ20X25-20 is discontinued. The direct replacement is the MBLJ20X25-20, which matches the 20mm bore, 25mm stroke, 20mm adjust code, and G1/8 port. The MBLJ upgrades the threaded covers to a riveted rolling-packed body.
The 20mm adjust code lets you trim the 25mm stroke at the rear, yielding a usable 5-25mm window. The adjuster is a travel stop, not a lock.
