This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ20X75-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10
The AirTAC Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 10 mm, giving a usable end-position window from 65 to 75 mm. This model is discontinued — the direct replacement is the MBLJ20X75-10.
- BoreØ20 mm
- Stroke75 mm
- Adjust window65–75 mm
- Port sizeG1/8
- Rod threadM8×1.25
- StatusDiscontinued → MBLJ20X75-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10
The AirTAC MALJ20X75-10 is a discontinued double-acting, double-rod adjustable-stroke mini cylinder. It has a 20mm bore, a 75mm stroke, and a 10mm rear adjuster, giving a usable end-position window of 65-75mm. The direct replacement is the MBLJ20X75-10, matching the bore, stroke, adjuster, G1/8 port, and mounting.
This SKU lacks the -S magnet, so it cannot accept a position sensor. The rear adjuster is a travel stop to fine-tune reach without external hardware; it is not a lock and will not hold a load without live air. The fixed rubber bumper softens end impact. Note the upgrade path: the MALJ uses threaded covers and the older CS1-M/DS1-M sensor family, while the MBLJ uses a riveted rolling-packed body and CMSG/DMSG/EMSG switches.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10 Technical Specifications
| Model | Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ20X75-10 |
| Bore size | Ø20 mm |
| Stroke | 75 mm |
| Adjustable window | 65 – 75 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ20X75-10 carries the same ratings.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 132 N | 132 N |
| 0.7 MPa | 185 N | — |
| Max (@1.0 MPa) | 27 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ20X75-10 matches these values.
Model Code: Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 20 | Bore size in mm (20/25/32/40). |
| ×75 | Nominal stroke length in mm. |
| -10 | Adjustable amount: trim the end to a 65–75 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10 Is Used
PCB Router Z-Axis Stop
Dial in the 65-75mm descent on a PCB depaneling router.
Dispenser Valve Height
Fine-tune the drop height for an epoxy dispensing valve. The 10mm rear adjuster lets you set the exact nozzle clearance without machining new brackets.
Lead Trimmer Strike
Trim through-hole component leads on a sequencer. The 132N pull force retracts the cutter cleanly, while the rubber bumper absorbs the impact of the rapid 800 mm/s cycle.
Replacing the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10 with MBLJ20X75-10
To replace this MALJ20X75-10, order the MBLJ20X75-10. Confirm the 20mm bore, 75mm stroke, 10mm adjust code, G1/8 port, PT thread, and FA/LB mounting (there is no back-cover or SDB option). Because this SKU lacks the -S magnet, it cannot take a sensor; if you need position detection, specify an MBLJ20X75-10S and use CMSG/DMSG/EMSG switches. The rear adjuster sets the end position but does not hold load without air; use an external lock for held loads. At 75mm, the stroke is moderate, but always ensure the rod is guided to prevent bending under side loads.
Upgrade checklist
- ✓ Order the MBLJ20X75-10 (same bore/stroke/adjust)
- ✓ Same 65–75 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ20X75-10 instead of this discontinued model.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-10 FAQ
Yes, the MALJ20X75-10 is discontinued. The direct replacement is the MBLJ20X75-10, which matches the 20mm bore, 75mm stroke, 10mm adjuster, G1/8 port, and FA/LB mounting. The MBLJ upgrades the body to a riveted rolling-packed design and uses CMSG/DMSG/EMSG sensors if you add the -S magnet option.
The 10mm rear adjuster creates a usable stroke window of 65-75mm. The adjuster is a travel stop, not a lock; it cannot hold a load without live air. This SKU has no magnet, so it cannot accept a position sensor.
