This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ20X75-75, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75
The AirTAC Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 75 mm, giving a usable end-position window from 0 to 75 mm. This model is discontinued — the direct replacement is the MBLJ20X75-75.
- BoreØ20 mm
- Stroke75 mm
- Adjust window0–75 mm
- Port sizeG1/8
- Rod threadM8×1.25
- StatusDiscontinued → MBLJ20X75-75
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75
The AirTAC MALJ20X75-75 is a discontinued double-acting mini cylinder with a 75 mm rear adjustable stroke stopper. Because the adjust code equals the stroke, you can dial the usable extension window from 0 to 75 mm without adding external stops.
The direct replacement is the MBLJ20X75-75, matching the bore, stroke, G1/8 port and force. This SKU has no magnet (-S), so it cannot take a position sensor. The MALJ uses a fixed rubber bumper and threaded covers, whereas the MBLJ upgrades to a riveted rolling-packed body. The adjuster sets the end position but does not hold load without live air.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75 Technical Specifications
| Model | Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ20X75-75 |
| Bore size | Ø20 mm |
| Stroke | 75 mm |
| Adjustable window | 0 – 75 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ20X75-75 carries the same ratings.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 132 N | 132 N |
| 0.7 MPa | 185 N | — |
| Max (@1.0 MPa) | 27 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ20X75-75 matches these values.
Model Code: Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 20 | Bore size in mm (20/25/32/40). |
| ×75 | Nominal stroke length in mm. |
| -75 | Adjustable amount: trim the end to a 0–75 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75 Is Used
Contact Pin Insertion
Adjust the end position to press connector pins into housings on an automated insertor, preventing over-travel and ensuring the bumper absorbs the 132 N pull load on retract.
Label Applicator Tamp
Fine-tune the tamp head reach from 0 to 75 mm for varying product heights on a packaging line, avoiding the need to swap physical stop collars for each SKU.
Replacing the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75 with MBLJ20X75-75
To replace the MALJ20X75-75, order the exact direct replacement MBLJ20X75-75. Confirm the 20 mm bore, 75 mm stroke, 75 mm adjust code, G1/8 port, and PT thread. Mounting is Basic, FA or LB only (no back cover or SDB). Note the adjuster is a travel stop, not a lock.
Upgrade checklist
- ✓ Order the MBLJ20X75-75 (same bore/stroke/adjust)
- ✓ Same 0–75 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ20X75-75 instead of this discontinued model.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-75 FAQ
Yes, the MALJ20X75-75 is discontinued. The direct replacement is the MBLJ20X75-75, which matches the 20 mm bore, 75 mm stroke, 75 mm adjust code, G1/8 port, and mounting. The MBLJ upgrades the threaded covers to a riveted rolling-packed body.
The 75 mm adjust code lets you trim the end position, creating a usable 0-75 mm window. The adjuster is a travel stop, not a lock, and cannot hold a load without live air. This SKU has no magnet, so it cannot accept a sensor.
