Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-40
2、Front/rear end caps feature threaded connection design;
3、Piston sealing adopts specialized bidirectional sealing structure with compact dimensions and integrated oil reservoir function;
4、Front end incorporates self-lubricating bearing guides for enhanced lubrication and directional stability;
5、Multiple rear mounting configurations enable flexible cylinder installation;
6、Available with various cylinder sizes and compatible mounting accessories for customized configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: MALJ20
AirTAC MALJ20X80-40 Adjustable Mini Cylinder Technical Details
- Model: MALJ20X80-40 (Standard adjustable type)
- Bore size: 20mm
- Stroke: 80mm (Adjustable stroke mechanism)
- Operating pressure: 0.05-0.9 MPa
- Medium: Clean air (Lubricated or non-lubricated)
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper (Both ends)
- Mounting type: Basic type (No pre-installed mounts)
- Rod end: Female thread M5x0.8
- Port size: M5x0.8 (Dual ports)
- Piston speed: 50-700 mm/s
- Seal material: NBR (Optional PU seals for high temps)
- Body material: Aluminum alloy (Hard anodized)
- Weight: 330g ±5% (Without accessories)
- Dimensions:
- Length: 144mm (Fully retracted)
- Width: 32mm (Body diameter)
- Height: 42mm (Including mounting bosses)
Ultra-compact linear actuator featuring precision stroke adjustment via external mechanical stoppers. The double-acting design enables precise bidirectional control, with corrosion-resistant construction ideal for humid environments. Integrated wear-resistant guide rings ensure smooth operation even under side load conditions.
- PCB handling robots - precise component placement
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer mechanisms
- Automated coffee machine brewing systems
- Micro-assembly jig positioners
Installation protocol:
For optimal performance, maintain 0.5-1mm end play during mounting.
Requires monthly lubrication (ISO VG32 recommended) in high-cycle applications.
Avoid angular misalignment exceeding ±2° during rod attachment.
- MALJ-MB20: Side-mounted bracket kit
- MALJ-SS20: Magnetic sensor slot compatible cylinder version
- ASM-MALJ20: Anti-rotation shaft modification kit
| Property | Property Value |
|---|---|
| sku | MALJ20X80-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 80 mm |
