Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-50
2、Front/rear end caps feature threaded connection design;
3、Piston sealing adopts specialized bidirectional sealing structure with compact dimensions and integrated oil reservoir function;
4、Front end incorporates self-lubricating bearing guides for enhanced lubrication and directional stability;
5、Multiple rear mounting configurations enable flexible cylinder installation;
6、Available with various cylinder sizes and compatible mounting accessories for customized configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: MALJ20
AirTAC MALJ20X80-50 Adjustable Miniature Cylinder Specifications
- Model: MALJ20X80-50
- Type: Single-acting spring return (adjustable cushioning)
- Bore size: Ø20mm
- Stroke: 80mm (±0.5mm tolerance)
- Rod thread: M5×0.8 external thread
- Operating pressure: 0.15–0.8 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (1/8" NPT optional)
- Cushion adjustment range: 2-5mm (both ends)
- Piston speed: 50-750 mm/s
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel SUS304
- Seals: NBR (nitrile rubber)
- Weight: 320g ±5g (without accessories)
- Dimensions:
- Total length: 136mm (at fully retracted position)
- Body diameter: Ø32mm
- Mounting base: 40mm × 20mm × 8mm
Ultra-compact pneumatic cylinder featuring dual adjustable rubber cushions for precise end-position damping control. The corrosion-resistant design includes a hardened piston rod surface (HV≥700) for extended lifespan in high-cycle applications. Integrated mounting slots allow direct installation without additional brackets.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in medical device manufacturing
- Carton flap control in packaging machinery
- Valve actuation in analytical instruments
- Semiconductor wafer positioning systems
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Avoid side load exceeding 3N·m. For vertical mounting,
maintain minimum 0.3 MPa pressure to ensure full stroke completion.
| Property | Property Value |
|---|---|
| sku | MALJ20X80-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 80 mm |
