This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ25X75-40, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40
The AirTAC Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 40 mm, giving a usable end-position window from 35 to 75 mm. This model is discontinued — the direct replacement is the MBLJ25X75-40.
- BoreØ25 mm
- Stroke75 mm
- Adjust window35–75 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ25X75-40
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40
The AirTAC MALJ25X75-40 is a discontinued double-acting, double-rod mini cylinder with a 40mm rear adjustable stroke stopper. This yields a usable end-position window of 35-75mm. The direct replacement is the MBLJ25X75-40, matching the bore, stroke, adjuster, force, and G1/8 port.
This SKU lacks a magnet (-S), so it cannot take a position sensor. The rear adjuster sets travel but is a stop, not a lock; it will not hold a load without live air. It uses a fixed rubber bumper, not an adjustable cushion. Upgrade details: the MALJ has threaded covers, while the MBLJ uses a riveted rolling-packed body.
Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40 Technical Specifications
| Model | Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ25X75-40 |
| Bore size | Ø25 mm |
| Stroke | 75 mm |
| Adjustable window | 35 – 75 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ25X75-40 carries the same ratings.
Theoretical Output Force (Ø25mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 206 N | 206 N |
| 0.7 MPa | 289 N | — |
| Max (@1.0 MPa) | 42 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ25X75-40 matches these values.
Model Code: Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 25 | Bore size in mm (20/25/32/40). |
| ×75 | Nominal stroke length in mm. |
| -40 | Adjustable amount: trim the end to a 35–75 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40 Is Used
PCB Router Depth Stop
Dial the end position within the 35-75mm window to set precise Z-axis plunging depth for a PCB depaneling router without machining new hard stops.
Label Applicator Reach
Fine-tune the extension reach on a packaging line label applicator, adjusting the stroke on the fly to match varying box widths without changing cylinders.
Replacing the Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40 with MBLJ25X75-40
To replace the MALJ25X75-40, order the MBLJ25X75-40. Confirm the 25mm bore, 75mm stroke, 40mm adjust code, G1/8 port, and PT thread form. Mounting is FA or LB only; there is no back-cover or SDB option. Because this SKU lacks the -S magnet, it cannot accept a CS1-M/DS1-M sensor, and the MBLJ upgrade would shift to CMSG/DMSG/EMSG switches if needed.
The adjuster is a travel stop, not a load lock.
Upgrade checklist
- ✓ Order the MBLJ25X75-40 (same bore/stroke/adjust)
- ✓ Same 35–75 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ25X75-40 instead of this discontinued model.
Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-40 FAQ
Yes, the MALJ25X75-40 is discontinued. The MBLJ upgrades the body to a riveted rolling-packed design from the original threaded covers.
The 75mm stroke with a 40mm rear adjuster gives a usable window of 35-75mm. It uses a fixed rubber bumper, and the adjuster is a travel stop, not a lock.
