This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X25-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 10 mm, giving a usable end-position window from 15 to 25 mm. This model is discontinued — the direct replacement is the MBLJ32X25-10.
- BoreØ32 mm
- Stroke25 mm
- Adjust window15–25 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X25-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10
The AirTAC MALJ32X25-10 is a discontinued double-acting mini cylinder with a 32 mm bore and a 25 mm stroke. It features a rear screw stopper that lets you trim the end position by up to 10 mm, giving a usable reach window of 15 to 25 mm without adding external stops. The direct replacement is the MBLJ32X25-10, matching the bore, stroke, port, and mounting.
This SKU has no magnet and cannot accept a position sensor. The adjuster is a travel stop, not a lock, so it will not hold a load without live air pressure. Upgrading to the MBLJ32X25-10 changes the sensor family from the legacy CS1-M/DS1-M to the modern CMSG/DMSG/EMSG switches, and swaps the threaded covers for a riveted rolling-packed body. The fixed rubber bumper softens end impact, but this is an adjustable stroke, not an adjustable cushion.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X25-10 |
| Bore size | Ø32 mm |
| Stroke | 25 mm |
| Adjustable window | 15 – 25 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X25-10 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X25-10 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×25 | Nominal stroke length in mm. |
| -10 | Adjustable amount: trim the end to a 15–25 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10 Is Used
PCB Router Z-Axis
Dial the 15-25 mm reach window to set router bit depth on a printed circuit board milling spindle without swapping mechanical spacers.
Dispenser Valve Tapping
Fine-tune the 25 mm stroke down to 15 mm to precisely tap a pneumatic glue dispenser valve open for exact shot sizing.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10 with MBLJ32X25-10
Replace the MALJ32X25-10 directly with the MBLJ32X25-10. Confirm the 32 mm bore, 25 mm stroke, 10 mm adjust code, G1/8 port, PT thread, and FA or LB mounting. This SKU lacks a magnet, so no sensor is needed unless your new MBLJ specifies one. The rear adjuster sets the end position but does not hold the load without air; use an external lock for holding.
Upgrade checklist
- ✓ Order the MBLJ32X25-10 (same bore/stroke/adjust)
- ✓ Same 15–25 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X25-10 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X25-10 FAQ
Yes, the MALJ32X25-10 is discontinued. The direct replacement is the MBLJ32X25-10, which matches the 32 mm bore, 25 mm stroke, 10 mm adjust code, G1/8 port, and FA/LB mounting.
The 10 mm adjust code gives a usable stroke window of 15-25 mm.
