This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X50-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 10 mm, giving a usable end-position window from 40 to 50 mm. This model is discontinued — the direct replacement is the MBLJ32X50-10.
- BoreØ32 mm
- Stroke50 mm
- Adjust window40–50 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X50-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10
The AirTAC MALJ32X50-10 is a discontinued 32mm bore, double-acting mini cylinder with a 50mm stroke and a 10mm rear adjustable stop. This gives a usable end-position window of 40-50mm. The direct replacement is the MBLJ32X50-10, matching bore, stroke, port and mounting.
This SKU lacks a magnet (-S), so it cannot accept a position sensor. The rear adjuster is a travel stop, not a lock; it sets the end position but will not hold a load without live air. The MALJ uses threaded covers and a fixed rubber bumper, whereas the MBLJ upgrade features a riveted rolling-packed body and CMSG/DMSG/EMSG sensors.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X50-10 |
| Bore size | Ø32 mm |
| Stroke | 50 mm |
| Adjustable window | 40 – 50 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X50-10 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X50-10 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×50 | Nominal stroke length in mm. |
| -10 | Adjustable amount: trim the end to a 40–50 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10 Is Used
Leather Embossing Press
Fine-tune the stroke end-position for a leather embossing press, ensuring the 346N pull retracts the tooling cleanly without tearing the material during high-speed cycling.
Bottle Capper Cam Return
Adjust the rear stop to synchronize the return stroke on a rotary bottle capper, trimming 10mm to match cap height variations without repositioning the cylinder body.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10 with MBLJ32X50-10
To replace the MALJ32X50-10, order the MBLJ32X50-10. Confirm the 32mm bore, 50mm stroke, 10mm adjust code, G1/8 port, M10x1.25 rod-end thread, and FA/LB mounting (no back cover or SDB). Because this SKU has no -S magnet, it cannot take a sensor; the MBLJ upgrade uses CMSG/DMSG/EMSG switches. Remember the adjuster is a stop, not a lock.
Upgrade checklist
- ✓ Order the MBLJ32X50-10 (same bore/stroke/adjust)
- ✓ Same 40–50 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X50-10 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-10 FAQ
Yes, the AirTAC MALJ32X50-10 is discontinued. The direct replacement is the MBLJ32X50-10, sharing the same 32mm bore, 50mm stroke, 10mm adjust code, G1/8 port, and FA/LB mounting. The MBLJ upgrades the body to a riveted rolling-packed design and uses CMSG/DMSG/EMSG sensors instead of the older CS1-M/DS1-M.
The -10 adjust code lets you trim up to 10mm at the rear, creating a usable end-position window of 40-50mm. The adjuster is a travel stop, not a lock, and cannot hold a load without air.
