This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X50-20, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 20 mm, giving a usable end-position window from 30 to 50 mm. This model is discontinued — the direct replacement is the MBLJ32X50-20.
- BoreØ32 mm
- Stroke50 mm
- Adjust window30–50 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X50-20
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20
The AirTAC MALJ32X50-20 is a discontinued double-acting mini cylinder with a 20 mm rear stroke adjuster, yielding a usable 30-50 mm end-position window. The direct replacement is the MBLJ32X50-20, matching the 32 mm bore, 50 mm stroke, and G1/8 port.
This SKU lacks a -S magnet, so it cannot accept a position sensor. The rear adjuster is a travel stop, not a lock; it sets the end position but will not hold a load without live air. Unlike the threaded covers on this MALJ, the MBLJ replacement uses a riveted rolling-packed body. Both rely on a fixed rubber bumper, meaning there is no adjustable air cushion.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X50-20 |
| Bore size | Ø32 mm |
| Stroke | 50 mm |
| Adjustable window | 30 – 50 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X50-20 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X50-20 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×50 | Nominal stroke length in mm. |
| -20 | Adjustable amount: trim the end to a 30–50 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20 Is Used
Aluminum Profile Notching
Trims the end position for a notching station on an aluminum extrusion line, adjusting the 20 mm range to hit exact miter cuts without repositioning the cylinder body.
Carton Flap Folding
Fine-tunes the flap-folding stroke on a packaging machine, using the fixed rubber bumper to soften the impact at the adjusted end position for reliable carton forming.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20 with MBLJ32X50-20
To replace this MALJ32X50-20, order the MBLJ32X50-20. Confirm the 32 mm bore, 50 mm stroke, 20 mm adjust code, PT G1/8 port, and FA or LB mounting (no back cover or SDB allowed). Because this SKU has no -S magnet, it cannot take a sensor; if you need sensing on the MBLJ upgrade, you must switch to the CMSG/DMSG/EMSG switch family.
Remember the adjuster is a stop, not a lock; add an external locking device if the assembly must hold position without air pressure.
Upgrade checklist
- ✓ Order the MBLJ32X50-20 (same bore/stroke/adjust)
- ✓ Same 30–50 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X50-20 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20 FAQ
Yes, the MALJ32X50-20 is discontinued. The direct replacement is the MBLJ32X50-20, which matches the 32 mm bore, 50 mm stroke, 20 mm adjust code, and G1/8 port. The MBLJ upgrades the body to a riveted rolling-packed design from the original threaded covers.
The -20 code means you can trim up to 20 mm at the rear, creating a usable 30-50 mm stroke window. The adjuster is a travel stop, not a lock, and cannot hold a load without live air.
