Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-20-LB
2. Front/rear end caps adopt threaded connection structure for secure assembly;
3. Piston seal utilizes special bidirectional sealing configuration with compact dimensions and oil reservoir function;
4. Integrated self-lubricating bearing in front end cap ensures superior guiding performance and lubrication retention;
5. Multiple rear cushioning configurations enable flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for custom system integration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MALJ32
AirTAC MALJ32X50-20-LB Adjustable Mini Cylinder Specifications
- Model: MALJ32X50-20-LB
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm (Φ20)
- Stroke: 50mm (adjustable cushion range: 3-10mm)
- Cushion type: External screw adjustment with rubber buffer
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Mounting style: Basic type (no built-in mounting brackets)
- Piston rod material: Stainless steel (SUS304)
- Cylinder tube: Aluminum alloy hard anodized
- Seal material: NBR (nitrile rubber)
- Weight: 220g ±5g
- Dimensions:
- Length (retracted): 90mm
- Width: 32mm (max body width)
- Height: 32mm (square body profile)
- Rod end thread: M6x1.0
- Protection rating: IP54 (standard wiper seal)
- Lubrication: Pre-lubricated (DOP oil film)
Ultra-compact square-body cylinder featuring external cushion adjustment screws for precise end-position deceleration control. The MALJ32 series combines space efficiency (32mm profile) with 200mm/s maximum piston speed capability. Anti-rotation design maintains tooling orientation, while the stainless steel piston rod resists side load wear. Requires 5μm filtered air and monthly lubrication for optimal performance.
- PCB board clamping in SMT machines
- Precision lens positioning in optical equipment
- Syringe actuation mechanisms in medical devices
- Label applicators in packaging lines
- Valve switching in beverage dispensing systems
Installation note:
Use alignment jig when mounting multiple cylinders in parallel.
Avoid lateral forces exceeding 15N. Cushion adjustment requires
1.5mm hex key (clockwise to soften, counter to harden).
| Property | Property Value |
|---|---|
| sku | MALJ32X50-20-LB |
| Adjustable Stroke | <20mm> |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <50mm> |
