This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X50-50, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 50 mm, giving a usable end-position window from 0 to 50 mm. This model is discontinued — the direct replacement is the MBLJ32X50-50.
- BoreØ32 mm
- Stroke50 mm
- Adjust window0–50 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X50-50
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50
The AirTAC MALJ32X50-50 is a discontinued double-acting mini cylinder with a 50mm rear adjuster. The direct replacement is the MBLJ32X50-50, matching the 32mm bore, 50mm stroke, G1/8 port, and force ratings. This SKU lacks a magnet (-S) and cannot take a position sensor.
It provides a usable stroke window of 0-50mm. The rear adjuster is a travel stop, not a lock, so it cannot hold a load without live air. The original MALJ uses threaded covers and a fixed rubber bumper; the MBLJ upgrade features a riveted rolling-packed body.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X50-50 |
| Bore size | Ø32 mm |
| Stroke | 50 mm |
| Adjustable window | 0 – 50 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X50-50 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X50-50 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×50 | Nominal stroke length in mm. |
| -50 | Adjustable amount: trim the end to a 0–50 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50 Is Used
PCB Depaneling Saw Stop
Sets a hard travel stop for a circular saw blade on a PCB depaneling router, using the 50mm window to fine-tune cut depth while relying on the fixed rubber bumper for impact absorption.
Connector Insertion Press
Provides variable end-position depth for pressing pin headers into plastic connectors, trimming up to 50mm to accommodate varying connector heights.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50 with MBLJ32X50-50
To replace this MALJ32X50-50, order the MBLJ32X50-50. Confirm the 32mm bore, 50mm stroke, 50mm adjust code, G1/8 port, PT threads, and FA/LB mounting (no back cover or SDB). Since this SKU has no -S magnet, you lose switches; the MBLJ upgrade would require CMSG/DMSG/EMSG sensors if you add a magnet. The adjuster sets the end position but does not lock the load.
Upgrade checklist
- ✓ Order the MBLJ32X50-50 (same bore/stroke/adjust)
- ✓ Same 0–50 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X50-50 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X50-50 FAQ
Yes, the MALJ32X50-50 is discontinued. The direct replacement is the MBLJ32X50-50, which matches the 32mm bore, 50mm stroke, 50mm adjust code, G1/8 port, and force ratings. The MBLJ upgrades the body to a riveted rolling-packed design from the original threaded covers.
The -50 adjust code lets you trim up to 50mm at the rear, creating a usable stroke window of 0-50mm. Note that this SKU lacks a magnet and cannot accept a position sensor.
