This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X75-30, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 30 mm, giving a usable end-position window from 45 to 75 mm. This model is discontinued — the direct replacement is the MBLJ32X75-30.
- BoreØ32 mm
- Stroke75 mm
- Adjust window45–75 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X75-30
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30
A rear screw lets you trim up to 30 mm of travel, giving a usable extension window of 45-75 mm. The direct replacement is the MBLJ32X75-30, matching the bore, stroke, adjust code, and G1/8 port.
This SKU has no magnet, so it cannot accept a position sensor. The rear adjuster is a travel stop, not a lock; it sets the end position but will not hold a load without live air. The original MALJ uses threaded covers and a fixed rubber bumper, while the MBLJ upgrade features a riveted rolling-packed body. Impact is softened by the bumper only, as there is no adjustable air cushion.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X75-30 |
| Bore size | Ø32 mm |
| Stroke | 75 mm |
| Adjustable window | 45 – 75 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X75-30 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X75-30 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×75 | Nominal stroke length in mm. |
| -30 | Adjustable amount: trim the end to a 45–75 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30 Is Used
Variable Stroke Forming Press
Adjusts the rear stop on a small bracket bending jig to tune the final bend depth in 1 mm increments, avoiding the need to swap out the entire cylinder for different part heights.
Carton Flap Tucking Arm
Trims the tucking arm extension by up to 30 mm to accommodate varying box sizes on a packaging line, relying on the fixed rubber bumper to absorb the repeated end-of-stroke impact.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30 with MBLJ32X75-30
To replace the MALJ32X75-30, specify the MBLJ32X75-30 to match the 32 mm bore, 75 mm stroke, 30 mm adjust code, G1/8 port, and PT thread. Mounting is Basic, FA, or LB only; there is no back cover or SDB option. Because this SKU lacks the -S magnet, it cannot support a sensor; if you need position detection, step up to an MBLJ32X75-30S and use the newer CMSG/DMSG/EMSG switches instead of the older CS1-M/DS1-M. The rear adjuster is a stop, not a lock; add an external locking valve for held loads.
Upgrade checklist
- ✓ Order the MBLJ32X75-30 (same bore/stroke/adjust)
- ✓ Same 45–75 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X75-30 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-30 FAQ
Yes, the MALJ32X75-30 is discontinued. The direct replacement is the MBLJ32X75-30, which matches the 32 mm bore, 75 mm stroke, 30 mm adjust code, and G1/8 port. The MBLJ upgrades the body to a riveted rolling-packed design from the original threaded covers, but retains the same force ratings and mounting footprint.
The -30 adjust code means you can trim up to 30 mm at the rear, creating a usable stroke window of 45 to 75 mm. Note that the adjuster is a travel stop, not a lock, and cannot hold a load without air pressure.
