This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X75-40, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 40 mm, giving a usable end-position window from 35 to 75 mm. This model is discontinued — the direct replacement is the MBLJ32X75-40.
- BoreØ32 mm
- Stroke75 mm
- Adjust window35–75 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X75-40
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40
The AirTAC MALJ32X75-40 is a discontinued double-acting mini cylinder with a 32mm bore and a 75mm stroke. It features a fixed rubber bumper and a rear adjuster that trims up to 40mm, giving a usable end-position window of 35-75mm. The direct replacement is the MBLJ32X75-40.
Because this SKU lacks the -S magnet, it cannot accept a position sensor. The adjuster is a travel stop, not a lock—it sets the end position but holds no load without live air. Upgrading to the MBLJ32X75-40 retains the PT G1/8 port and M10x1.25 rod thread but swaps the old threaded covers for a riveted rolling-packed body.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X75-40 |
| Bore size | Ø32 mm |
| Stroke | 75 mm |
| Adjustable window | 35 – 75 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X75-40 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X75-40 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×75 | Nominal stroke length in mm. |
| -40 | Adjustable amount: trim the end to a 35–75 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40 Is Used
Dispenser Nozzle Height
Fine-tune the stroke down from 75mm to 35mm on a fluid dispensing head, adjusting the rear stopper to prevent the nozzle from crashing into sensitive substrates.
Leather Press Tonnage
Apply 346N pull force at 0.5MPa on a small leather embossing press, using the fixed rubber bumper to soften the end impact and protect delicate stamping dies.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40 with MBLJ32X75-40
To replace this MALJ32X75-40, order the exact direct replacement MBLJ32X75-40: same 32mm bore, 75mm stroke, 40mm adjust code, G1/8 port, and FA/LB mounting (no back cover or SDB). Since this SKU has no -S magnet, you lose sensors entirely; the MBLJ upgrade enables the modern CMSG/DMSG/EMSG switch family if you add the magnet option. Remember the rear adjuster is a stop, not a lock.
At 75mm stroke, rod side-load is minimal, but always guide the tooling to prevent rod bending.
Upgrade checklist
- ✓ Order the MBLJ32X75-40 (same bore/stroke/adjust)
- ✓ Same 35–75 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X75-40 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-40 FAQ
Yes, the MALJ32X75-40 is discontinued. The direct replacement is the MBLJ32X75-40, which matches the 32mm bore, 75mm stroke, 40mm adjust code, and G1/8 port. The MBLJ upgrade uses a riveted rolling-packed body instead of threaded covers.
The -40 adjust code lets you trim the 75mm stroke down by up to 40mm, creating a usable 35-75mm window. The adjuster is a travel stop, not a lock.
