This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X75-50, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 50 mm, giving a usable end-position window from 25 to 75 mm. This model is discontinued — the direct replacement is the MBLJ32X75-50.
- BoreØ32 mm
- Stroke75 mm
- Adjust window25–75 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X75-50
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50
The AirTAC MALJ32X75-50 is a discontinued double-acting, double-rod mini cylinder with a 32 mm bore and 75 mm stroke. The rear adjuster lets you trim the end position by up to 50 mm, creating a usable stroke window of 25-75 mm. The direct replacement is the MBLJ32X75-50, matching the bore, stroke, force, and port.
This SKU has no magnet (-S omitted), so it cannot accept a position sensor. The rear adjuster is a travel stop, not a lock; it sets the end position but will not hold a load without live air. The original MALJ uses threaded covers and a fixed rubber bumper, while the MBLJ upgrade features a riveted rolling-packed body. End impact is softened by the bumper only—there is no adjustable air cushion.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X75-50 |
| Bore size | Ø32 mm |
| Stroke | 75 mm |
| Adjustable window | 25 – 75 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X75-50 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X75-50 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×75 | Nominal stroke length in mm. |
| -50 | Adjustable amount: trim the end to a 25–75 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50 Is Used
Bottle Flange Trimmer
Adjust the rear stop to tune the 75 mm extension, ensuring the 346 N pull force retracts the trimmer blade cleanly without over-travel.
Carton Flap Folder
Fine-tune the end position to match varying carton heights, using the fixed rubber bumper to absorb the impact of the folding arm at stroke end.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50 with MBLJ32X75-50
To replace the MALJ32X75-50, order the MBLJ32X75-50. Confirm the 32 mm bore, 75 mm stroke, 50 mm adjust code, G1/8 port, and PT thread. Mounting is Basic, FA, or LB only—there is no back-cover or SDB option. Because this SKU lacks the -S magnet, it cannot take a sensor; upgrading to an MBLJ with -S moves you to the CMSG/DMSG/EMSG switch family. Remember the adjuster is a stop, not a lock.
Upgrade checklist
- ✓ Order the MBLJ32X75-50 (same bore/stroke/adjust)
- ✓ Same 25–75 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X75-50 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-50 FAQ
Yes, the MALJ32X75-50 is discontinued. The direct replacement is the MBLJ32X75-50, which matches the 32 mm bore, 75 mm stroke, 50 mm adjust code, G1/8 port, and mounting. The MBLJ upgrades the body to a riveted rolling-packed design from the original threaded covers.
The usable stroke window is 25-75 mm, set by trimming the 50 mm rear adjuster. The maximum force is 82 kgf at 1.0 MPa. The adjuster is a travel stop, not a lock.
