Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-10
2. Front/rear end caps adopt threaded connection structure for secure assembly;
3. Piston seal utilizes special bidirectional sealing configuration with compact dimensions and oil reservoir function;
4. Integrated self-lubricating bearing in front end cap ensures superior guiding performance and lubrication retention;
5. Multiple rear cushioning configurations enable flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for custom system integration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MALJ32
AirTAC MALJ32X80-10 Adjustable Miniature Cylinder Technical Details
- Model: MALJ32X80-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø32mm (±0.1mm tolerance)
- Stroke length: 80mm (adjustable via built-in stroke limiter)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Cushioning: Rubber buffer with adjustable damping
- Port thread: M5×0.8 (standard) or NPT1/8 (optional)
- Piston rod material: Chrome-plated SUS304 stainless steel
- Barrel material: Anodized aluminum alloy AL6063
- Seal material: High-wear resistance NBR/PU
- Temperature range: -20℃ to 90℃ (dry air required below 0℃)
- Weight: 620g ±3% (without accessories)
- Dimensions: 138mm(L) × 32mm(W) × 32mm(H) (fully retracted)
- ISO standard: 6432 compliant (miniature series)
- Mounting options: Basic front flange (MF1), optional side lug (MA1) or rear pivot (MP4)
Ultra-compact linear actuator featuring 360° adjustable stroke control through its rotating end cap mechanism. The precision-ground rod and double-sealed construction ensure ≤0.05mm repeat positioning accuracy. Includes built-in magnet for magnetic sensor compatibility (Inductive sensor: AISI 1010 steel required).
- PCB handling robots in electronics manufacturing
- Dispenser nozzle positioning in food packaging
- Micro-assembly jigs for watch components
- Laboratory sample handling systems
- Cleanroom automation with ISO Class 5 compliance
Installation guidelines:
Lubricate with ISO VG32 turbine oil before initial use. Maximum side load: 15N.
For stroke adjustment: Loosen lock nut, rotate end cap (1 full rotation = 2mm stroke change),
then re-tighten to 1.2N·m torque. Maintain 0.5mm minimum stroke buffer.
| Property | Property Value |
|---|---|
| sku | MALJ32X80-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 80 mm |
