This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X80-20, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 20 mm, giving a usable end-position window from 60 to 80 mm. This model is discontinued — the direct replacement is the MBLJ32X80-20.
- BoreØ32 mm
- Stroke80 mm
- Adjust window60–80 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X80-20
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20
The AirTAC MALJ32X80-20 is a discontinued 32mm bore, double-acting mini cylinder with a 20mm rear adjustable stroke stopper. The direct replacement is the MBLJ32X80-20, matching the bore, stroke, adjuster code, G1/8 port, and FA/LB mounting options.
This non-magnet SKU lacks a -S code and cannot accept a position sensor. The rear adjuster is a travel stop, not a lock; it sets the end position but will not hold a load without live air pressure. The original MALJ uses threaded covers and a fixed rubber bumper, while the current MBLJ upgrade features a riveted rolling-packed body.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X80-20 |
| Bore size | Ø32 mm |
| Stroke | 80 mm |
| Adjustable window | 60 – 80 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X80-20 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X80-20 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×80 | Nominal stroke length in mm. |
| -20 | Adjustable amount: trim the end to a 60–80 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20 Is Used
Carton Flap Folder
Fine-tune the folding arm reach on a packaging line; the rear stopper lets you trim up to 20mm to compensate for varying cardboard thicknesses without adding external spacers.
Pneumatic Press Locator
Position a small 32mm bore locator pin against an aluminum housing, adjusting the end position by a few millimeters to align parts before the main 563N clamping action fires.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20 with MBLJ32X80-20
To replace the MALJ32X80-20, order the exact MBLJ32X80-20. Confirm the 32mm bore, 80mm stroke, 20mm adjust code, G1/8 PT port, and M10x1.25 rod-end thread. Mounting is FA or LB only; there is no back-cover or SDB option. Because this SKU lacks the -S magnet, it cannot take a sensor, whereas upgrading to an MBLJ-S allows modern CMSG/DMSG/EMSG switches instead of the legacy CS1-M/DS1-M.
The 20mm adjuster is a travel stop, not a lock; use an external lock for held loads.
Upgrade checklist
- ✓ Order the MBLJ32X80-20 (same bore/stroke/adjust)
- ✓ Same 60–80 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X80-20 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-20 FAQ
Yes, the MALJ32X80-20 is discontinued. The direct replacement is the MBLJ32X80-20, which matches the 32mm bore, 80mm stroke, 20mm adjuster, G1/8 port, and FA/LB mounting. The MBLJ upgrades the body to a riveted rolling-packed design from the original threaded covers.
The usable stroke window is 60-80mm (80mm stroke minus the 20mm rear adjuster). The adjuster is a travel stop, not a lock.
