Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-30
2. Front/rear end caps adopt threaded connection structure for secure assembly;
3. Piston seal utilizes special bidirectional sealing configuration with compact dimensions and oil reservoir function;
4. Integrated self-lubricating bearing in front end cap ensures superior guiding performance and lubrication retention;
5. Multiple rear cushioning configurations enable flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for custom system integration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MALJ32
AirTAC MALJ32X80-30 Adjustable Miniature Cylinder Specifications
- Model: MALJ32X80-30
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 80mm (adjustable range: 0-80mm)
- Rod diameter: 12mm
- Operating pressure: 0.05-1.0 MPa
- Medium: Clean compressed air (ISO8573-1:2010 Class 3)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Rubber buffer + external stroke adjustment
- Mounting type: 4x M5 threaded holes (base mounting)
- Port size: M5x0.8 (G1/8 adaptor included)
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (standard), optional FKM
- Weight: 550g ±5%
- Dimensions:
- Extended length: 153mm
- Retracted length: 73mm
- Body width: 40mm
- Height (with mounting base): 46mm
Compact pneumatic actuator featuring unique stroke adjustment mechanism with ±1mm positioning accuracy. The dual-lock structure prevents accidental stroke changes during operation. Integrated magnet for position sensing compatibility (sensor not included). Maintenance-free design with self-lubricating guide bushings.
- Precision part insertion in PCB assembly lines
- Modular tooling position adjustment systems
- Medical device manufacturing actuators
- Packaging machine flap control mechanisms
- Semiconductor wafer handling equipment
Installation tip:
For optimal performance, maintain 0.5-1mm clearance between adjustable stopper and cylinder body during stroke setting. Lubricate with ISO VG32 turbine oil if used in high-cycle (>5CPM) applications.
- MAL-M32H: Heat-resistant variant (up to 120℃)
- ASN04-01: Magnetic proximity sensor kit
- SC-L32: Shock absorber for high-speed applications
| Property | Property Value |
|---|---|
| sku | MALJ32X80-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 80 mm |
