This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X80-40, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 40 mm, giving a usable end-position window from 40 to 80 mm. This model is discontinued — the direct replacement is the MBLJ32X80-40.
- BoreØ32 mm
- Stroke80 mm
- Adjust window40–80 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X80-40
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40
The AirTAC MALJ32X80-40 is a discontinued 32mm bore, double-acting adjustable-stroke mini cylinder. It provides a usable end-position window of 40-80mm by trimming up to 40mm at the rear screw. The direct replacement is the MBLJ32X80-40, which matches the bore, stroke, adjust code, G1/8 port, and mounting footprint.
This SKU lacks the -S magnet option, so it cannot accept a position sensor; upgrading to the MBLJ requires CMSG/DMSG/EMSG switches if sensing is needed. The MALJ uses threaded covers and a fixed rubber bumper, while the MBLJ features a riveted rolling-packed body. The rear adjuster is a travel stop that sets the end position; it does not hold load without live air.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X80-40 |
| Bore size | Ø32 mm |
| Stroke | 80 mm |
| Adjustable window | 40 – 80 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X80-40 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X80-40 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×80 | Nominal stroke length in mm. |
| -40 | Adjustable amount: trim the end to a 40–80 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40 Is Used
Bottle Capper Height Set
Fine-tune the downward reach of a capping head on a rotary filler without adding spacer plates, trimming 0-40mm off the 80mm stroke to match varying cap heights.
Leather Press Creasing
Adjust the end position to control the fold depth on a leather creasing jig, relying on the fixed rubber bumper to soften the impact at the end of travel.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40 with MBLJ32X80-40
To replace the MALJ32X80-40, order the MBLJ32X80-40. Confirm the 32mm bore, 80mm stroke, 40mm adjust code, G1/8 port, and M10x1.25 rod-end thread. Mounting is FA or LB only; there is no back-cover or SDB option. Since this is a no-S SKU, it cannot take a sensor. The adjuster is a stop, not a lock; use an external lock for held loads.
Upgrade checklist
- ✓ Order the MBLJ32X80-40 (same bore/stroke/adjust)
- ✓ Same 40–80 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X80-40 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-40 FAQ
Yes, the MALJ32X80-40 is discontinued. The direct replacement is the MBLJ32X80-40, which matches the 32mm bore, 80mm stroke, 40mm adjust code, and G1/8 port. The MBLJ uses a riveted rolling-packed body instead of threaded covers.
The -40 adjust code lets you trim up to 40mm at the rear, giving a usable stroke window of 40-80mm. The adjuster is a travel stop, not a lock.
