This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X90-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 10 mm, giving a usable end-position window from 80 to 90 mm. This model is discontinued — the direct replacement is the MBLJ32X90-10.
- BoreØ32 mm
- Stroke90 mm
- Adjust window80–90 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X90-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10
The AirTAC MALJ32X90-10 is a discontinued 32mm bore, double-acting adjustable-stroke mini cylinder. The -10 adjust code lets you trim the rear end position by up to 10mm, creating a usable stroke window of 80-90mm. The direct replacement is the MBLJ32X90-10, matching the bore, stroke, force, and G1/8 port.
This SKU has no -S magnet, so it cannot accept a position sensor. The original MALJ uses threaded covers and a fixed rubber bumper; the MBLJ upgrade features a riveted rolling-packed body. The rear adjuster acts as a mechanical travel stop to fine-tune the reach without adding external spacers, but it will not hold a load without live air pressure.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X90-10 |
| Bore size | Ø32 mm |
| Stroke | 90 mm |
| Adjustable window | 80 – 90 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X90-10 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X90-10 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×90 | Nominal stroke length in mm. |
| -10 | Adjustable amount: trim the end to a 80–90 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10 Is Used
Sheet Metal Shear Stop
Set a repeatable 80mm back-gauge depth for a small pneumatic shear, letting the fixed rubber bumper absorb the 346N pull shock during rapid retraction.
Plastic Trim Cutter
Fine-tune the cut depth on an injection-molded trim station, preventing the 12mm rod from over-traveling and chipping the stationary blade.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10 with MBLJ32X90-10
To replace the MALJ32X90-10, order the direct replacement MBLJ32X90-10. Confirm the 32mm bore, 90mm stroke, 10mm adjust code, G1/8 port, PT threads, and FA/LB mounting (no back cover or SDB). Since this SKU lacks the -S magnet, it cannot take a sensor; if you need position detection, the MBLJ replacement requires CMSG/DMSG/EMSG switches rather than the older CS1-M/DS1-M. The adjuster is a travel stop, not a lock; add an external pneumatic lock to hold loads safely.
This 32mm model provides a strong middle ground for mid-force clamping.
Upgrade checklist
- ✓ Order the MBLJ32X90-10 (same bore/stroke/adjust)
- ✓ Same 80–90 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X90-10 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-10 FAQ
Yes, the MALJ32X90-10 is discontinued. The direct replacement is the MBLJ32X90-10, which matches the 32mm bore, 90mm stroke, 10mm adjust code, force, and G1/8 port. The MBLJ upgrades the body to a riveted rolling-packed design, and if you ever add a sensor, it uses CMSG/DMSG/EMSG switches instead of the old CS1-M/DS1-M.
This double-acting double-rod cylinder has a 32mm bore, a 12mm rod, M10x1.25 rod-end thread, and a G1/8 port. The -10 adjust code provides a usable stroke window of 80-90mm. It uses a fixed rubber bumper, not an adjustable air cushion.
