Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-40
2. Front/rear end caps adopt threaded connection structure for secure assembly;
3. Piston seal utilizes special bidirectional sealing configuration with compact dimensions and oil reservoir function;
4. Integrated self-lubricating bearing in front end cap ensures superior guiding performance and lubrication retention;
5. Multiple rear cushioning configurations enable flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for custom system integration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MALJ32
AirTAC MALJ32X90-40 Adjustable Miniature Cylinder Specifications
- Model: MALJ32X90-40
- Bore size: 32mm
- Stroke: 90mm (±5mm adjustable)
- Operation type: Double-acting
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5×0.8 (G1/8 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Mounting type: Basic foot mounting (ISO 15552 standard)
- Weight: 0.85kg ±3%
- Dimensions: 178mm(L) × 50mm(W) × 50mm(H)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
- Protection rating: IP54 (standard), IP67 optional
Ultra-compact pneumatic cylinder featuring patented buffer adjustment technology, providing precise end-position control through 360° rotatable cushioning screws. The double-sealed piston design ensures leak-proof operation in high-cycle applications. Corrosion-resistant construction with ISO-standard mounting interfaces enables easy integration into automated systems.
- Precision pick-and-place units in SMT assembly lines
- Clamping mechanisms in micro-machining centers
- Valve actuation in compact fluid control systems
- Medical device positioning components
- Robotic end-effector tool changers
- Pharmaceutical packaging equipment
Installation tip:
For optimal performance, align cushion screws with movement axis during adjustment.
Recommended maintenance: Apply light machine oil (ISO VG32) every 500,000 cycles
through the built-in lubrication port. Avoid side-load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MALJ32X90-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 90mm |
