Airtac MALJ32 Adjustable Mini Cylinder MALJ32X90-50
2. Front/rear end caps adopt threaded connection structure for secure assembly;
3. Piston seal utilizes special bidirectional sealing configuration with compact dimensions and oil reservoir function;
4. Integrated self-lubricating bearing in front end cap ensures superior guiding performance and lubrication retention;
5. Multiple rear cushioning configurations enable flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for custom system integration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MALJ32
AirTAC MALJ32X90-50 Adjustable Mini Cylinder Specifications
- Model: MALJ32X90-50
- Type: Adjustable stroke double-acting mini cylinder
- Bore size: 32mm
- Stroke: 90mm (max), adjustable from 40-90mm via stopper
- Adjustment range: 50mm (minimum stroke 40mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable cushion screw
- Mounting style: Basic foot mount (MF1) with optional accessories
- Port size: M5x0.8 (standard), optional NPT1/8
- Piston rod thread: M10x1.25
- Material: Aluminum alloy body, CRMo steel piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 520g ±2%
- Dimensions:
- Extended length: 176mm
- Retracted length: 86mm
- Body width: 40mm
- Height with rod: 52mm
Ultra-compact linear actuator featuring external stroke adjustment mechanism with locknut-secured position setting. The dual-chamber design provides consistent force output (178N at 0.6MPa) in both extension/retraction directions. Precision-ground rod with hard chrome plating ensures wear resistance. Includes magnetic piston for position sensing compatibility.
- PCB board clamping/fixturing in electronics manufacturing
- Precision dosing valve actuation in pharmaceutical equipment
- Micro-part positioning in watchmaking machinery
- Automated lens adjustment mechanisms
- Semiconductor wafer handling systems
Installation note:
Maximum side load capacity 15N. Use rod-end bearings for angular misalignment compensation.
Lubricate with ISO VG32 hydraulic oil if used in high-cycle applications (>5Hz).
For stroke adjustment: Loosen locknut, turn stopper clockwise to reduce stroke (1 full rotation = 1.5mm adjustment).
| Property | Property Value |
|---|---|
| sku | MALJ32X90-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 90mm |
