This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X95-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 10 mm, giving a usable end-position window from 85 to 95 mm. This model is discontinued — the direct replacement is the MBLJ32X95-10.
- BoreØ32 mm
- Stroke95 mm
- Adjust window85–95 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X95-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10
The AirTAC MALJ32X95-10 is a discontinued 32mm bore, double-acting mini cylinder with a 95mm stroke and a 10mm rear adjustable stopper. This gives a usable end-position window of 85-95mm. The direct replacement is the MBLJ32X95-10, matching bore, stroke, adjust code, G1/8 port and mounting.
Two non-obvious details: the rear adjuster is a travel stop, not a lock, so it will not hold a load without live air. Also, this specific SKU lacks a magnet (-S), so it cannot accept a position sensor. The original MALJ uses threaded covers and the CS1-M/DS1-M sensor family, while the MBLJ upgrade features a riveted rolling-packed body and CMSG/DMSG/EMSG sensors. End impact is softened by a fixed rubber bumper, not an adjustable air cushion.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X95-10 |
| Bore size | Ø32 mm |
| Stroke | 95 mm |
| Adjustable window | 85 – 95 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X95-10 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X95-10 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×95 | Nominal stroke length in mm. |
| -10 | Adjustable amount: trim the end to a 85–95 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10 Is Used
Wire Harness Forming Jig
Trims the 10mm rear travel window to set exact bend depths for cable looms without machining new hard stops.
Bottle Capper Head
Fine-tunes the downstroke end position to apply consistent torque on plastic caps, relying on the fixed rubber bumper to soften impact.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10 with MBLJ32X95-10
To replace the MALJ32X95-10, order the direct replacement MBLJ32X95-10. Confirm the 32mm bore, 95mm stroke, 10mm adjust code, PT G1/8 port, M10x1.25 rod thread, and FA/LB mounting (no back cover or SDB). Because this SKU has no -S magnet, it cannot take a sensor. The rear adjuster sets the 85-95mm end position but is a stop, not a lock.
Upgrade checklist
- ✓ Order the MBLJ32X95-10 (same bore/stroke/adjust)
- ✓ Same 85–95 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X95-10 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-10 FAQ
Yes, the MALJ32X95-10 is discontinued. The direct replacement is the MBLJ32X95-10, matching the 32mm bore, 95mm stroke, 10mm adjuster, G1/8 port and FA/LB mounting. The MBLJ upgrades the body to a riveted rolling-packed design from the original threaded covers.
The 95mm stroke with a 10mm rear adjuster yields a usable window of 85-95mm. Note that because this SKU lacks the -S magnet, it cannot accept a position sensor.
