This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X95-20, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 20 mm, giving a usable end-position window from 75 to 95 mm. This model is discontinued — the direct replacement is the MBLJ32X95-20.
- BoreØ32 mm
- Stroke95 mm
- Adjust window75–95 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X95-20
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20
The AirTAC MALJ32X95-20 is a discontinued double-acting mini cylinder with a 32 mm bore and 95 mm stroke. A rear stopper screw trims up to 20 mm, giving a usable end-position window of 75-95 mm. The direct replacement is the MBLJ32X95-20, matching bore, stroke, adjust code, G1/8 port, and mounting.
The rear adjuster is a travel stop, not a lock; it sets the end position but holds no load without live air. This SKU has no magnet (-S), so it cannot take a position sensor. The original MALJ uses threaded covers and a CS1-M/DS1-M sensor family, while the MBLJ upgrade features a riveted rolling-packed body and CMSG/DMSG/EMSG sensors. Impact is softened by a fixed rubber bumper, not an adjustable air cushion.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X95-20 |
| Bore size | Ø32 mm |
| Stroke | 95 mm |
| Adjustable window | 75 – 95 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X95-20 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X95-20 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×95 | Nominal stroke length in mm. |
| -20 | Adjustable amount: trim the end to a 75–95 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20 Is Used
Tube Bender Stop
Set the rear stop on a manual tube bender to halt the carriage at 85 mm, ensuring repeatable bend starts without repositioning the hardware.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20 with MBLJ32X95-20
To replace the MALJ32X95-20, order the MBLJ32X95-20. Confirm the 32 mm bore, 95 mm stroke, 20 mm adjust code, G1/8 port, PT threads, and FA/LB mounting. This SKU lacks a magnet, so no sensor is used; the MBLJ upgrade adds CMSG/DMSG/EMSG switch compatibility. Remember the rear adjuster is a stop, not a lock.
At 95 mm stroke, watch for rod bending under side loads—keep the load guided to prevent rod damage.
Upgrade checklist
- ✓ Order the MBLJ32X95-20 (same bore/stroke/adjust)
- ✓ Same 75–95 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X95-20 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-20 FAQ
Yes, the MALJ32X95-20 is discontinued. The direct replacement is the MBLJ32X95-20, which matches the 32 mm bore, 95 mm stroke, 20 mm adjust code, G1/8 port, and FA/LB mounting. The MBLJ upgrades the body to a riveted rolling-packed design and uses CMSG/DMSG/EMSG sensors.
The usable adjustable window is 75-95 mm. The rear adjuster is a travel stop, not a lock, and will not hold a load without live air pressure.
