This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X95-30, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 30 mm, giving a usable end-position window from 65 to 95 mm. This model is discontinued — the direct replacement is the MBLJ32X95-30.
- BoreØ32 mm
- Stroke95 mm
- Adjust window65–95 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X95-30
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30
The AirTAC MALJ32X95-30 is a discontinued double-acting double-rod mini cylinder with a 32mm bore and 95mm stroke. It is replaced directly by the MBLJ32X95-30. The rear adjuster allows you to trim up to 30mm of travel, giving a usable end-position window of 65-95mm.
This -30 code sets a travel stop, not a load lock. The original MALJ uses threaded covers and a fixed rubber bumper, while the MBLJ upgrade features a riveted rolling-packed body. This specific SKU lacks a magnet and cannot accept a position sensor.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X95-30 |
| Bore size | Ø32 mm |
| Stroke | 95 mm |
| Adjustable window | 65 – 95 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X95-30 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X95-30 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×95 | Nominal stroke length in mm. |
| -30 | Adjustable amount: trim the end to a 65–95 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30 Is Used
Print Head Registration
Dialing the 65-95mm reach window lets flexo printing machines fine-tune the head down-stroke without machining new hard stops.
Carton Flap Folding
Packaging lines use the 346N pull force to tuck carton flaps, adjusting the 30mm stop to match varying box heights on the fly.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30 with MBLJ32X95-30
To replace the MALJ32X95-30, order the MBLJ32X95-30. Confirm the 32mm bore, 95mm stroke, 30mm adjust code, G1/8 port, M10x1.25 rod thread, and FA/LB mounting (no back cover or SDB). Because this SKU has no -S magnet, it cannot take a sensor; the MBLJ upgrade uses CMSG/DMSG/EMSG switches.
The rear adjuster sets the end position but does not hold the load without live air.
Upgrade checklist
- ✓ Order the MBLJ32X95-30 (same bore/stroke/adjust)
- ✓ Same 65–95 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X95-30 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X95-30 FAQ
Yes, the MALJ32X95-30 is discontinued. The direct replacement is the MBLJ32X95-30, which matches the 32mm bore, 95mm stroke, 30mm adjust code, and G1/8 port. The MBLJ upgrades the body to a riveted rolling-packed design.
The -30 adjuster is a travel stop that lets you shorten the 95mm stroke down to a 65mm minimum, but it does not hold the load without live air.
