This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is MBLJ40X30-30-S — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the MBLJ40X30-30-S in place of this model. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S
The AirTAC Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 30 mm, giving a usable end-position window from 0 to 30 mm. This model is discontinued — the drop-in replacement is the MBLJ40X30-30-S.
- BoreØ40 mm
- Stroke30 mm
- Adjust window0–30 mm
- Port sizeG1/4
- Rod threadM12×1.25
- StatusDiscontinued → MBLJ40X30-30-S
About the Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S
The AirTAC MALJ40X30-30-S is a discontinued double-acting, single-rod mini cylinder with a rear adjustable stroke stopper. It delivers 628 N push and 528 N pull at 0.5 MPa, with a 40 mm bore and G1/4 port. The -30 adjust code lets you dial the end position back by 30 mm, creating a usable stroke window from 0 to 30 mm. The exact drop-in replacement is the MBLJ40X30-30-S, matching bore, stroke, force, port, and mounting.
This cylinder uses a fixed rubber bumper, not an adjustable air cushion. The rear adjuster is a travel stop, not a lock; it sets the end position but will not hold a load without live air. For load-holding, use an external lock. Upgrade details: the MALJ has threaded covers and uses CS1-M / DS1-M sensors for its -S magnet, while the MBLJ replacement features a riveted rolling-packed body and uses CMSG / DMSG / EMSG sensors.
Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S Technical Specifications
| Model | Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ40X30-30-S |
| Bore size | Ø40 mm |
| Stroke | 30 mm |
| Adjustable window | 0 – 30 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ40X30-30-S carries the same ratings.
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | — |
| Max (@1.0 MPa) | 128 kgf | |
Single-rod force, same as a standard MAL of this bore. The MBLJ40X30-30-S matches these values.
Model Code: Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 40 | Bore size in mm (20/25/32/40). |
| ×30 | Nominal stroke length in mm. |
| -30 | Adjustable amount: trim the end to a 0–30 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S Is Used
Print Head Registration
Dial the 0-30 mm stroke window to set precise contact depth for a flexo print head, using the 628 N push force to impress plates accurately.
Pneumatic Spot Welder
Adjust the rear stop to control electrode approach distance on a spot welder, preventing deformation while delivering 880 N at 0.7 MPa.
PCB Edge Dampener
Fine-tune the retraction end point on a PCB conveyor edge guide, using the fixed rubber bumper to soften the impact of the 16 mm rod.
Replacing the Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S with MBLJ40X30-30-S
To replace the MALJ40X30-30-S, order the drop-in MBLJ40X30-30-S. Confirm the 40 mm bore, 30 mm stroke, 30 mm adjust code, G1/4 port, PT thread, and FA or LB mounting. There is no back-cover or SDB option. The -S magnet means a sensor family change from CS1-M / DS1-M to CMSG / DMSG / EMSG. The adjuster is a stop, not a lock.
For sizing, step down to the 32 mm bore (402 N push at 0.5 MPa) if you need less force, or step up to a custom larger bore if you need more than 628 N. The 16 mm hard-chrome rod handles the 30 mm stroke easily without side-load bending risks.
Upgrade checklist
- ✓ Order the MBLJ40X30-30-S (same bore/stroke/adjust)
- ✓ Same 0–30 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ40X30-30-S instead of this discontinued model.
Airtac MALJ40 Adjustable Mini Cylinder MALJ40X30-30-S FAQ
Yes, the MALJ40X30-30-S is discontinued. The exact drop-in replacement is the MBLJ40X30-30-S, which matches the 40 mm bore, 30 mm stroke, 30 mm adjust code, G1/4 port, and FA/LB mounting. The MBLJ upgrades the body to a riveted rolling-packed design and changes the -S magnet sensor family from CS1-M / DS1-M to CMSG / DMSG / EMSG.
The -30 adjust code lets you trim up to 30 mm at the rear, giving a usable stroke window from 0 to 30 mm. The adjuster is a travel stop, not a lock. Force figures at 0.5 MPa are 628 N push and 528 N pull. At 0.7 MPa, push is 880 N. The maximum force is 128 kgf at 1.0 MPa.
