Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202
The AirTAC Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202 is a genuine male branch tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale branch tee
- SeriesPEB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202
The AirTAC PEB1202 is a male branch tee from AirTAC's resin one-touch range. Two Dia 12 mm tube ports form a straight run, and a 1/4in PT male stud branches off at 90 degrees, so you can tap a feed line for a drop, a valve island or an actuator without cutting the main run or fitting a separate junction block.
Connection is genuinely one-touch: push the polyurethane or soft nylon tube into the port and the internal chuck grips it under a stainless spring gasket; press the POM release ring and the tube slides straight back out. The brass stud arrives with sealant already on the thread, so no extra tape is needed on the 1/4in PT port. This is the resin profile: 0-1.0 MPa working pressure, -750 mmHg vacuum, 1.5 MPa proof pressure and -20 to +70 C. The PBT housing and brass stud make it a compact, low-cost branch point for standard factory air.
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202 Technical Specifications
| Model | Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202 |
|---|---|
| Type | Male branch tee |
| Series | PEB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202
| PEB | Male branch tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202 Is Used
Branch drop to a clamp cylinder
Tee off a Dia 12 mm main air line feeding a pneumatic press and run the 1/4in stud straight into the clamp cylinder port, keeping the run intact for downstream tools.
Vacuum branch on an ejector line
Rated to -750 mmHg, the tee can split a vacuum supply to a pick-and-place ejector while the main run continues to a second suction cup station.
Sensor tap on a packaging line
Branch a Dia 12 mm conveyor-blast feed down to a 1/4in PT air sensor or jet nozzle on a carton-sealing machine without interrupting the belt cleaning circuit.
Is the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202 the Right Part?
On the 1/4in PEB ladder, Dia 12 is the top of the range - there is no larger tube above it, and the only step down is the PEB1002 on Dia 10 mm. Stepping down to Dia 10 trades a smaller bore (so more pressure drop on long branches) for a slimmer fitting that suits tighter panel layouts; if you need Dia 12 with a bigger port, the ladder moves to 3/8in thread at PEB1203. Match the stud to a 1/4in PT tapped port - not BSPP or NPT, which this catalogue does not offer.
Tube size must match exactly: a Dia 12 mm port will not seal reliably on 1/2in or 10 mm tube, and no other one-touch shape (straight PC, union PE, elbow PL) gives you the perpendicular branch this part provides. If the branch must pass through a panel wall instead, look at PMF bulkhead connectors rather than forcing a tee onto a surface.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202 FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), negative pressure -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. It joins Dia 12 mm soft nylon or polyurethane tube on two ports and carries a 1/4in PT male branch stud. The housing is PBT with a brass stud, POM release ring and stainless spring gasket, and the thread arrives with sealant applied.
No tape is required - AirTAC ships the threaded stud with sealant already on it, and M5-size parts in the same family use a gasket instead. Yes to vacuum: the fitting is rated to -750 mmHg, so it suits branch lines on ejector and suction circuits, provided your tube is also vacuum-rated.
