Airtac PEB T-Shaped Straight Thread Tee Connector PEB401
The AirTAC Airtac PEB T-Shaped Straight Thread Tee Connector PEB401 is a genuine male branch tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale branch tee
- SeriesPEB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PEB T-Shaped Straight Thread Tee Connector PEB401
The PEB401 is an AirTAC PEB male branch tee, the smallest push-to-connect branch fitting in the resin one-touch range. It takes Dia 4 mm soft nylon or polyurethane tube and screws into a 1/8 inch PT male port, with the branch leg leaving at 90 degrees so a third circuit can be fed from a single supply point. To connect, you push the tube straight into the collet until it bottoms out - a stainless spring gasket and the POM chuck grip it against the brass body - and a press on the release ring lets it slide back out.
This is the resin and brass spec profile, not the metal BP line: working pressure 0 to 1.0 MPa, vacuum down to -750 mmHg, proof pressure 1.5 MPa, and a service window of -20 to +70 C. The 1/8 inch thread arrives with pre-applied sealant, so no additional tape or paste is needed before fitting. Dia 4 is the starting point of the PEB ladder, which makes this part the natural choice where a 4 mm pilot or signal line must split without adapters.
Airtac PEB T-Shaped Straight Thread Tee Connector PEB401 Technical Specifications
| Model | Airtac PEB T-Shaped Straight Thread Tee Connector PEB401 |
|---|---|
| Type | Male branch tee |
| Series | PEB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PEB T-Shaped Straight Thread Tee Connector PEB401
| PEB | Male branch tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PEB T-Shaped Straight Thread Tee Connector PEB401 Is Used
Pilot signal tap on a pneumatic valve manifold
Screw the 1/8 stud into a spare manifold port and branch a 4 mm pilot line to a second valve station, letting one regulator feed two circuits from a single push-in point.
Pressure sensor take-off on a test jig
Tee a 4 mm sensing line off the main air feed at a fixture so a compact pressure switch or gauge reads circuit pressure without disturbing the actuator supply.
Small suction-cup split on an electronics pick-and-place head
Split the vacuum feed at the gantry head: the branch leg feeds a second 4 mm cup line, keeping tubing runs short and the head footprint minimal.
Is the Airtac PEB T-Shaped Straight Thread Tee Connector PEB401 the Right Part?
Dia 4 is the smallest tube PEB makes, so there is no step down - the only step up is PEB601, the same branch tee in Dia 6. Moving to Dia 6 buys more bore for longer runs or higher flow demand, but check that your cylinder, sensor or regulator port still accepts a 4 mm line; a Dia 6 fitting will not grip 4 mm tube. On the thread side, PEB4M5 gives the identical tee with an M5x0.8 stud (which uses a sealing gasket rather than thread sealant), and PEB402 steps the port up to 1/4 inch while keeping the 4 mm tube end. Match the thread to the port you actually have - forcing a 1/8 stud into a 1/4 tapped hole with tape is a leak waiting to happen. If you need the branch to pass through a panel wall instead of a port, a PM bulkhead connector is the right shape, not this tee.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PEB T-Shaped Straight Thread Tee Connector PEB401 FAQ
The PEB401 is a PEB male branch tee for Dia 4 mm soft nylon or polyurethane tube with a 1/8 inch PT male thread. Working pressure is 0 to 1.0 MPa (0 to 10 kgf/cm2), vacuum capability is -750 mmHg (10 Torr), proof pressure is 1.5 MPa, and the working temperature range is -20 to +70 C. Standard colour is grey; the release button is POM and the thread ships with sealant pre-applied.
No. The chuck in the PEB401 is sized for Dia 4 mm tube only - a 6 mm tube will not enter, and a nominal 5/32 inch (4 mm nominal) tube from another standard should still be verified at exactly 4 mm OD with a metric tolerance. For 6 mm lines order PEB601 instead. Soft nylon and soft polyurethane are the approved materials; rigid nylon or metal tube will not seal in a one-touch collet.
