Airtac PHW F Thread Swivel Tee Fitting PHW602
The AirTAC Airtac PHW F Thread Swivel Tee Fitting PHW602 is a genuine double universal male elbow for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeDouble universal male elbow
- SeriesPHW
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PHW F Thread Swivel Tee Fitting PHW602
The PHW602 is an AirTAC PHW double universal male elbow: a one-touch push-in fitting with a 1/4" male PT thread on one end and a Dia 6 mm tube socket on the other, joined by two swivel joints. Because the fitting articulates in two planes, the tube can enter from an angle that a fixed PL elbow cannot reach, and the male thread can be screwed into the port at whatever clock position the sealant needs. Push the tube home and the stainless chuck grips it; press the release ring to free it.
This is the resin and brass one-touch profile: working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum down to -750 mmHg (10 Torr), proof pressure 1.5 MPa, and a service temperature of -20 to +70 C with soft nylon or polyurethane tube. The body is PBT on a brass stud, with a POM release button, aluminium-alloy guide and NBR O-ring. Note that the PHW range starts at 1/8" thread - there is no M5 version in this series.
Airtac PHW F Thread Swivel Tee Fitting PHW602 Technical Specifications
| Model | Airtac PHW F Thread Swivel Tee Fitting PHW602 |
|---|---|
| Type | Double universal male elbow |
| Series | PHW |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PHW F Thread Swivel Tee Fitting PHW602
| PHW | Double universal male elbow. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PHW F Thread Swivel Tee Fitting PHW602 Is Used
Welding fixture clamp circuits
Robotic weld cells position clamp cylinders at odd angles inside the fixture frame. The double universal joint lets 6 mm PU tube swing into the cylinder port from two directions, avoiding the tight bend radius that kinks small tube.
Rotary index table actuation
On a rotary indexing table, the pneumatic feed to the rotary actuator turns with the table. A PHW602 at the port takes up the changing approach angle in both planes while the chuck holds the 6 mm tube under vibration.
Cartoning machine guard routing
Packaging machine guard interiors leave little straight run between valve manifold and ejector cylinder. The two swivel sections of this elbow steer the 6 mm nylon tube around corner posts where a fixed-angle elbow would force an over-bend.
Is the Airtac PHW F Thread Swivel Tee Fitting PHW602 the Right Part?
PHW602 is the Dia 6 tube entry on the 1/4" thread rung of the PHW ladder, which supports Dia 6, 8 and 10 at this thread. Stepping up to PHW802 buys you a Dia 8 bore feeding larger actuators; there is no Dia 4 option at 1/4" on a PHW - the smallest PHW tubes (Dia 4) only come on the 1/8" thread, so if you need Dia 4 with double-universal articulation you move to the PHW4-01 instead. For the same Dia 6 tube on a smaller port, PHW601 keeps the shape but drops the thread to 1/8".
Match the 1/4" thread to the port, not the tube: the thread arrives with sealant pre-applied, so no extra tape is needed on a PT port. Choose a PHW over a plain PL elbow when the tube must approach from an oblique angle in two directions; choose a PM bulkhead when the line has to pass through a panel wall instead. The tube OD must match exactly - this socket will not hold 1/4" (6.35 mm) tube, only genuine 6 mm OD soft nylon or polyurethane.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PHW F Thread Swivel Tee Fitting PHW602 FAQ
It joins Dia 6 mm soft nylon or polyurethane tube to a 1/4" male PT thread. Working pressure is 0-1.0 MPa (0-10 kgf/cm2), it handles vacuum to -750 mmHg (10 Torr), proof pressure is 1.5 MPa, and the service temperature range is -20 to +70 C. The body is PBT with a brass stud, POM release button, aluminium-alloy guide, stainless spring gasket and NBR O-ring.
Both the threaded stud and the tube socket rotate relative to the centre body, so you can align the 1/4" thread for sealing and then swing the tube entry to the angle the run needs - something a fixed PL elbow cannot do. Sealing relies on the pre-applied thread sealant on the stud, not on the swivels, so the joints stay dry on the outside once assembled. Remember the tube must be exactly 6 mm OD; the socket will not grip 1/4 inch (6.35 mm) tube.
