Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R
The AirTAC Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R is a single acting, push type (spring return) pen-size mini cylinder with direct front-cover mounting (M3×0.5 thread). A single air port drives the push stroke on a Ø6mm bore, 20mm stroke; the return spring resets the rod when air is released.
- BoreØ6 mm
- Stroke20 mm
- Port sizeM5×0.8
- Front-mount threadM3×0.5
- Acting typePush, single acting
- ReturnSpring
About the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R
The AirTAC PSBR6X20R is a single-acting push-type pen cylinder featuring a direct M3x0.5 front-cover mounting thread. Air entering the M5x0.8 port extends the rod, while an internal spring retracts it on air loss for fail-safe retraction. It supplies about 10.6 N of net push at 0.5 MPa.
Built with a SUS316L stainless barrel and a slim 6 mm body, it saves space in tight jigs. The fixed TPU bumper decelerates the rod near stroke ends. For smooth operation, plan for a safe working load of roughly 6 N, which is about 60 percent of the rated force.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R Technical Specifications
| Model | Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R |
|---|---|
| Series | PSBR JIS pen-size front-mount cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 20 mm |
| Acting type | Single acting, push type (spring return) |
| Front-mount thread | M3×0.5 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.3 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Front cover carries the mounting thread (M3×0.5); barrel is SUS316L. Forces below are NET spring-deducted values. Confirm against the product label.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are usable push forces after the return spring is subtracted, from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R
| PSBR | JIS pen-size front-mount single acting, push type (spring return) series. |
|---|---|
| 6 | Bore size in mm. |
| ×20 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| U / R | Back cover: U 90° side inlet or R axial inlet (bore-dependent). |
Mounting: direct front-cover thread (M3×0.5). Related PBR-family variants: PBR (double acting), PTBR (single-acting pull).
Where the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R Is Used
Micro Part Ejector
Uses the spring-return push to eject small molded components from a die, ensuring the rod safely retracts if air pressure drops.
Panel Pusher
Extends to nudge lightweight electronic panels into a test socket, relying on the 6.4 N safe working load for gentle contact.
Lab Valve Trigger
Cycles a delicate sampling valve in a compact analytical rig where the SUS316L barrel handles damp environments.
Is the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R the Right Cylinder?
This 6 mm bore provides 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. If your task needs less force, review the PSBR series limits, but if you need more power, step up to the 8 mm bore yielding 18.7 N at 0.5 MPa. The internal spring requires a minimum 0.3 MPa pressure before motion begins.
The direct M3x0.5 front-mount thread bolts straight to your fixture, and the R axial inlet handles in-line plumbing. It lacks a sensor magnet. Ensure your load stays coaxial, as the 3 mm rod is for thrust, not side load.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Bolt directly through the front cover (M3×0.5)
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.3 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Match bolt size and engagement to the front thread.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X20R FAQ
It delivers 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. Because it is spring-return, a minimum 0.3 MPa is required to overcome the spring and move the rod.
It mounts directly via the front-cover M3x0.5 thread. The R back cover provides an axial air inlet for in-line plumbing, separate from the front mount.
