Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R
The AirTAC Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R is a single acting, push type (spring return) pen-size mini cylinder with direct front-cover mounting (M3×0.5 thread). A single air port drives the push stroke on a Ø6mm bore, 60mm stroke; the return spring resets the rod when air is released.
- BoreØ6 mm
- Stroke60 mm
- Port sizeM5×0.8
- Front-mount threadM3×0.5
- Acting typePush, single acting
- ReturnSpring
About the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R
The AirTAC PSBR6X60R is a single-acting push, spring-return pen-size mini cylinder. It delivers 10.6 N of net push at 0.5 MPa. The M3x0.5 front-cover thread bolts straight to your fixture, saving space. An M5x0.8 port supplies air, while the R axial inlet keeps plumbing in-line.
Built with a SUS316L stainless barrel, this unit is fail-safe retracted on air loss. A fixed TPU bumper cushions the stroke ends. Plan for a safe working load of about 6 N, which is roughly 60 percent of the rated force. It can also lift about 0.5 kg vertically with a 2:1 margin.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R Technical Specifications
| Model | Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R |
|---|---|
| Series | PSBR JIS pen-size front-mount cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 60 mm |
| Acting type | Single acting, push type (spring return) |
| Front-mount thread | M3×0.5 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.3 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Front cover carries the mounting thread (M3×0.5); barrel is SUS316L. Forces below are NET spring-deducted values. Confirm against the product label.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are usable push forces after the return spring is subtracted, from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R
| PSBR | JIS pen-size front-mount single acting, push type (spring return) series. |
|---|---|
| 6 | Bore size in mm. |
| ×60 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| U / R | Back cover: U 90° side inlet or R axial inlet (bore-dependent). |
Mounting: direct front-cover thread (M3×0.5). Related PBR-family variants: PBR (double acting), PTBR (single-acting pull).
Where the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R Is Used
Micro Part Ejection
Pushes small molded components out of a tight cavity. The spring return retracts the rod automatically when air stops.
Panel Pusher
Acts as a compact diverter for lightweight circuit boards. The direct front mount threads directly into the machine subplate.
Lab Valve Actuation
Cycles a small fluid valve in damp environments. The SUS316L barrel resists corrosion while the R inlet keeps plumbing neat.
Is the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R the Right Cylinder?
This 6mm bore model provides 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. Stepping up to the 8mm bore yields 18.7 N at 0.5 MPa if you need more force. The internal return spring requires a minimum 0.3 MPa to move the rod. At 60mm stroke, the slim Ø3 mm piston rod needs an external guide or linear bearing to prevent side-load binding.
The direct front-cover mount eliminates brackets. Confirm your M3x0.5 bolt engagement. The R back cover provides an axial air inlet. This configuration ships without a sensor magnet.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Bolt directly through the front cover (M3×0.5)
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.3 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Match bolt size and engagement to the front thread.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60R FAQ
It provides 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. The internal spring sets a 0.3 MPa minimum pressure before the rod moves. If air loss occurs, the spring holds the rod fail-safe retracted.
It mounts directly via an M3x0.5 front-cover thread. The barrel is SUS316L stainless steel. This specific model has no sensor magnet and uses an R axial back cover inlet.
